After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Official MD32 Bulldozer for sale
XCMG Official MD32 Bulldozer for sale
Quantity:
- + /EA

Content:

Or choose from these questions:
What is the best price you can offer?
Do you support customization?
What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

Specs & Compare
Details
Specs & Compare
Select 3 models for comparison
Dimension(Long * Breadth * High)
Machine Weight
Model Number
Brand Name
Place of Origin
Certification
Engineering & Construction Machinery
8916×4130×3708.5mm
40490kg
--
XCMG
China
--
+   Add a Product
+   Add a Product

Summary

  • Dimension(Long * Breadth * High):8916×4130×3708.5mm
  • Machine Weight:40490kg
  • Brand Name:XCMG
  • Place of Origin:China

Specifications

  • weight:40490.000kg
  • Condition:New
  • Moving Type:Other
  • Operation weight(kg):34390
  • max.towing force(kN):300
  • max.towing force:235kn
  • min.turning radius(m):3.94
  • Max.grdient(°):30
  • Min.ground clearance(mm):500
  • Forward(km/h):3.6/6.6/11.5
  • Reverse(km/h):4.4/7.8/13.5
  • Ground length(mm):3150
  • Track centers(mm):2140
  • Fuel tank capacity(L):600

Packaging & Shipping

  • Delivery Lead Time:7 days for ready goods
  • Minimum Order:1 Piece
  • Supply Ability:10,000 Set/ Sets per Month
  • Total Quantity In Stock:Over 5000
  • Delivery Port:Any Port In China

XCMG Official MD32 Bulldozer for sale

XCMG Official MD32 Bulldozer for sale


DescriptionSpecifications
L×W×H(mm)8916×4130×3708.5
Operation weight(kg)40490
Operation weight(kg)34390
max.towing force(kN)300
max.towing force235kn
min.turning radius(m)3.94
Max.grdient(°)30
Min.ground clearance(mm)500
Forward(km/h)3.6/6.6/11.5
Reverse(km/h)4.4/7.8/13.5
Ground length(mm)3150
Track centers(mm)2140
Fuel tank capacity(L)600
Noise

Noise level at seated position

Engine

Cummins

ModelNTA855-C360S10
TypeTurbocharged diesel、Inter cooled 、vertical
Number of cylinders-bore×stroke() 6-139.7×152.4
piston displacement(L)14
rated horsepower(kW)235
rated revolution(rpm)2000
max torque(N.m/rpm)1509/1400
fuel consumption(g/kW.h)≤213
Starting modestart motor
start motor24V、11kW
alternatorsilicon rectified generator 28V、35A
battery24V(12×2)-195Ah×2
transmission
torque converter3-element 1-stage 1-phase
Output unitfixed axis type、gear drive、pressure lubrication
Transfer casefixed axis type、gear drive、pressure lubrication
power-shift  planetary aear transmissionplanetary gear ,multiple-disc clutch,hydraulically connected forced
running speed(km/h)1st forward0-3.6
2nd forward0-6.6
3rd forward0-11.5
1st reverse0-4.4
2nd  reverse0-7.8
3rd reverse0-13.5
main-drive shaftspiral bevel gear ,splash lubrication
steering clutchwet,multi-disc,spring compression ,hyclraulically separated
steeting brakewet,foot pedal fuel pressure booster ,with stopping brake
final drivereduction,splash lulcrinction
final drive ratioClass A45/12=3.75
Second level55/12=4.5833
running system
suspensionswing type balance bean suspension structure
type of sprocketsegmented
type of trackassembled type ,single tooth
Caterpilar typeSealed type
track pitch(mm)228.6
Track tensioning mechanismTightening cylinder. Butter tight
width of track shoes(mm)560
tooth height(mm)80
type of trackSingle –row combined
number fo track shoes41
No.of track shoes2
No.fo road  wheels7
operation system
accelerator controlhand accelerator and accelerator pedal reduction
gear-shiftingmanual hydraulic control
steering and brake controlhydraulic booster
W×H(mm)straight blade4130×1590
straight blade  weight(kg)5150
shovel capacity(m3)straight blade10.4
max,digging depth(mm)560
max.lifting height(mm)1560
max.inclination height(mm)1000
cutting angle(°)55
lifting speed m/s0.3
Natural down level (mm/15min)≤150
productivity (At distance of 40M)(m3/h)480
Ripper typethree-teeth、single-tooth
tooth depth(mm)three teeth
two teeth
three teeth ripperdigging depth(mm)842
lifting height(mm)883
single tooth ripperdingging depth(mm)1250
lifting depth(mm)955
three teeth ripper  weith(5350
single tooth ripper  weith(5000
Rated pressure(Mpa)13.7
Type of pressure pumpCBZ4200
Rated flow(L/min)355
Control valve typespool valve
blade elevating cylinder bore ×numberφ140×φ75×1346
tilt cylinder bore×numberφ225×φ90×80
riper cylinder bore ×numberφ225×φ90×540
type of cylinderCBJ40-B45L-B1K
rated delivery(L/min)90
rated pressure(Mpa)2.5
rated delivery(L/min)200
rated pressure(Mpa)2
coolingwater cooled
