XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price

  • XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
  • XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
  • XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
  • XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
  • XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
  • XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
  • XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
  • XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price

Share:
XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
FOB for Piling Mach Reference Price:Get Latest Price
$30000.00-$50000.00 1 / EA (Min. Order)
Model: XSC3/160
Engine: Cummins
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Dimension(L*W*H):7960×2500×7370mm
  • Weight:13.3ton
  • Power(W):113kw
  • Model Number:XSC3/160
  • Brand Name:XCMG
  • Place of Origin:Xuzhou, China
  • Power Type: Diesel engines
  • Type:Truck mounted water well drilling rig
Specifications
  • weight:13300.000kg
  • Condition:New
  • Moving Type:Wheel

XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price

XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig.



The overall layout of XCMG truck mounted water well drilling rig XSC3/160 is reasonable, the drilling efficiency is high, and it is suitable for air, mud and other drilling techniques.



XSC3/160 truck mounted water well drilling rig is widely used in resource drilling projects such as water wells, ground source heat pumps, emergency rescue, deep geothermal, micro-pile, coalbed methane, shale gas, etc.



XSC series of deep (water) well drilling rigs adopt a number of electro-mechanical and hydraulic integration technologies such as full hydraulic control, top driving force head, etc. The products have been exported to more than 20 countries and regions such as Africa, South America, Southeast Asia, and Russia.



Technical features of XSC series truck mounted deep well drilling rig:



1, High-efficiency and energy-saving hydraulic system

-Intelligent matching system flow and pressure according to load demand, high efficiency and energy saving.

-Proportional control of the main action. Convenient speed regulation, no impact, high control accuracy.

-Intelligent oil dispersion keeps the system in the best operating environment at all times, with high efficiency.



2, Strong top driving force head

-Large diameter main shaft, strong slag discharge capacity, especially suitable for reverse circulation construction.

-External floating device can reduce drill pipe thread wear and increase service life.



3, Fully automatic loading and unloading rod mechanism

-Equipped with tiltable power head, unscrewing double grippers, hydraulic slips, and optional automatic rod changing system, which can realize full automation of rod loading and unloading operations.



4, Road conditions adaptive intelligent all-terrain off-road chassis

-Multi-axle steering intelligent control, multiple steering modes, flexible rotation, small turning diameter.

-Pneumatic suspension, with good driving smoothness and strong passing ability, suitable for driving in harsh road conditions such as mud, sand, snow, and mountains.



5, Intelligent Internet of Things and Remote Monitoring System

-Through the three-in-one global positioning system, mobile phone communication network, and the Internet, the intelligent identification, positioning, tracking, monitoring and management of drilling rigs can be realized.



6, Telescopic feed system

-Cylinder-wire rope double-speed feed system, multiple drilling modes, higher efficiency.

-The telescopic mast ensures small size during transportation and large stroke during work, which is suitable for long drill pipe and casing operations.



XCMG Manufacturers 300m Small Truck Mounted Water Well Drilling Rig price

Drilling capacity

Drilling depth

m

300Ф89



Max Passing diameter

mm

Ф330

feed system

Max lifting capacity

kN

160



Max feed force

kN

80











Max lifting speed

m/min

32



Max lowering speed

m/min

60



Stroke

mm

3800

power head

max torque

Nm

6600/3300











Max speed

r/min

95/190



spindle diameter

mm

Ф55









engine

model

/

QSB5.9-C150



Rated power

kW

113

winch

lifting power

kN

15

foam pump

maximum delivery

L/min

18



Max pressure

MPa

15

Manifold

diameter

mm

Ф55



Max pressure

MPa

8

Working dimension



mm

7960×2500×7370

Transportation dimension



mm

8100×2500×3250

Total Weight



t

13.3
