XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

  • XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
  • XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
  • XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
  • XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
  • XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
  • XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
  • XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

Share:
XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
FOB for OEM Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
Summary
  • Model Number:JP20C2
  • Brand Name:XCMG
  • Place of Origin:Jiangsu, China
  • Size:10620*2500*3880mm
  • Max Work Height:20m
  • Fuel Type:Diesel
  • Emission Standard:Euro 4
  • Tank Capacity:7001 - 10000L
  • Horsepower:351 - 450hp
  • Transmission Type:Manual
  • Type:RESCUe
  • Drive Wheel:6x4
Details
  • weight:32250.000kg
  • Condition:New
  • Moving Type:Other

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2.



1.The JP20C2 water tower fire truck is a multi-functional fire fighting vehicle that adds the extinguishing fluid and a foam device on a high-spray vehicle, and combines a large tanker, a foam car, and a high-ejection fire engine. It is mainly used for fire suppression in low-rise buildings such as cities and towns, industrial and mining enterprises, and petrochemical enterprises, oil tanks, and warehouses.



2.The high-spray vehicle adopts the brand ZZ5347V4647E5 type II vehicle chassis. The upper vehicle arm frame adopts a two-section folding arm structure, and each movement mechanism adopts an electrically controlled hydraulic driving mode, which makes the vehicle easy to operate, flexible in movement, safe and reliable, and practical. It adopts the automatic control of the limit position to decelerate and stop, so that the operation is rapid, labor-saving, convenient, and stable, and has a large range of speed adjustment, micro-vibration, and accurate movement.

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

Overall size : (L x W x H)

10620×2500×3880mm

Full-load weight

32250kg

Maximum truck speed

≥90km/h

Minimum turning diameter

≤23m

Approach angle

≥16°

Departure angle

≥9°

Maximum gradeability

≥25%

Outrigger span

Outrigger longitudinal span

5835mm

Outrigger transversal span

2270mm

Maximum working height

20m

Maximum working radius

12m

Jib rack luffing angle

First section arm (related to water level): 0°~85°

Second section arm (related to water level): 0°~170°

Turning range

360° continuous rotation

Leg deployment time

≤20s

Boom operation time

≤45s

Rotation speed of the boom

0.5~1.5r/min

Fire pump

Rated flow

≥50 L/s

Rated pressure

≥1.4 MPa

Fire monitor

Model

PLKD64

Rated flow

50 L/s

Rated pressure

≤0.9 MPa

Shoot range

≥60m

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale

XCMG Official Mini Fire Truck 20m water and foam tower fire truck JP20C2 firefighter trucks price for sale
