XCMG official XE135B 13 ton crawler excavator hydraulic excavator small Digging machine price for sale
Summary
- Rated Speed:5.16km/h
- Max Digging Radius:8296mm
- Machine Weight:13000kg
- Maximum Digging Depth:5538mm
- Maximum Digging Height:8641mm
- Bucket capacity: 0.4-0.52
- Operating Weight:13000kg
- Model Number:XE135B
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
Specifications
- weight:13000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG
official XE135B 13-ton crawler excavator hydraulic excavator small Digging machine.
XE135B
featuring high efficiency and energy conservation, is mainly used for earth
working conditions. The powerful lsuzu BB-4BG1TRP engine and high-end Kawasaki
hydraulic system are matched perfectly, which can guarantee the product
reliability and define hgh-efficiency operation and fuel economy. With
strengthened structural parts, it is applicable for earth working, road
construction and municipal engineering, and allow you to get digging and
loading operations done easily.
Advanced
Configuration:
1.
Environmentally friendly and energy saving
*
Customized high-power engine is more powerful,
*
Adopting XCMG's proprietary matching technology to achieve higher operation
efficiency and lower fuel consumption.
*
Minimized impact on emission systems and make itmore environmentally friendly.
2.
Multiple applications
*
Different boom, arm and bucket combinations can provide excellent all-around
versatlity.
*Multi-functional
work tool system can meet various operation- al requirements including digging,
breaking and so on.
3.
Comfortable operating experience
* Air
conditioner and heater ensure the appropriate temperature.
* Rear
camera and right camera provide better view.
*
Air-suspension seat equipped with electric heating function.
*
Integrated control panel and large display screen provide multiple information.
|
Description |
Unit |
Parameter value |
||
|
Operating weight |
Kg |
13000 |
||
|
Bucket capacity |
m³ |
0.4-0.52 |
||
|
Engine |
Model |
/ |
ISUZU BB-4BG1TRP |
|
|
Style |
Direct injection |
/ |
√ |
|
|
Four strokes |
/ |
√ |
||
|
Water cooling |
/ |
√ |
||
|
Turbo-charging |
/ |
√ |
||
|
Air to air intercooler |
/ |
× |
||
|
No. of cylinders |
/ |
4 |
||
|
Output power |
kw/rpm |
72.7/2200 |
||
|
torque/speed |
N.m |
337.6/1600 |
||
|
Displacement |
L |
4.329 |
||
|
|
Travel speed（H/L) |
km/h |
5.16/3.03 |
|
|
Rotating speed |
r/min |
12.3 |
||
|
Gradeability |
° |
≤35 |
||
|
Ground pressure |
kPa |
42 |
||
|
Bucket digging force |
kN |
85 |
||
|
Arm crowd force |
kN |
65 |
||
|
Maximum traction |
kN |
134 |
||
|
|
Main pump |
/ |
2 |
|
|
Rated flow of main pump |
L/min |
2×123 |
||
|
Pressure of prime valve |
MPa |
31.4/34.3 |
||
|
Pressure of travel system |
MPa |
34.3 |
||
|
Pressure of swing system |
MPa |
25 |
||
|
Pressure of pilot system |
MPa |
3.9 |
||
|
Oil Capacity |
Fuel tank capacity |
L |
250 |
|
|
Hydraulic tank capacity |
L |
130 |
||
|
Engine oil capacity |
L |
14 |
||
|
|
Overall length |
mm |
7770 |
|
|
Overall width |
mm |
2512 |
||
|
Overall height |
mm |
2880 |
||
|
Width of platform |
mm |
2512 |
||
|
Length of crawler |
mm |
3660 |
||
|
Overall width of chassis |
mm |
2490 |
||
|
Width of crawler |
mm |
500 |
||
|
Track length on ground |
mm |
2910 |
||
|
Crawler gauge |
mm |
1990 |
||
|
Clearance under counterweight |
mm |
964 |
||
|
Min. ground clearance |
mm |
478 |
||
|
Min. tail swing radius |
mm |
1805 |
||
|
Height of track |
mm |
|||
|
|
Max. digging height |
mm |
8641 |
|
|
Max. dumping height |
mm |
6181 |
||
|
Max. digging depth |
mm |
5538 |
||
|
Max. vertical wall digging depth |
mm |
4727 |
||
|
Max. digging reach |
mm |
8296 |
||
|
Min. swing radius |
mm |
2335 |
||
