China XCMG 45 ton 9m reach stacker for 20ft container price

  • China XCMG 45 ton 9m reach stacker for 20ft container price
  • China XCMG 45 ton 9m reach stacker for 20ft container price
  • China XCMG 45 ton 9m reach stacker for 20ft container price
  • China XCMG 45 ton 9m reach stacker for 20ft container price
  • China XCMG 45 ton 9m reach stacker for 20ft container price
  • China XCMG 45 ton 9m reach stacker for 20ft container price
  • China XCMG 45 ton 9m reach stacker for 20ft container price

Share:
China XCMG 45 ton 9m reach stacker for 20ft container price
FOB for OEM Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: XCS4531T
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
China XCMG 45 ton 9m reach stacker for 20ft container price
China XCMG 45 ton 9m reach stacker for 20ft container price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
  • 360-Degree VR Videos
Summary
Specifications
  • weight:65000.000kg

China XCMG 45 ton 9m reach stacker for 20ft container price

China XCMG 45 ton reach stacker for 20ft container.



XCMG Reach Stackers:

XCMG reach stackers include K series (diesel engine) and E series (pure electric) reach stackers.



XCMG K Series Reach Stackers:

XCMG's K series reach stacker features good safety, high degree of intelligence, comfortable operation, energy saving and environmental protection, and it meets the requirements of the high-end market.



Applicable Working Conditions of XCMG K Series Reach Stacker XCS4531T:

IOS 20ft standard container



Highlights of XCMG XCS4531T Reach Stacker:

1. Powered by Volvo engine and Dana gearbox.

2. Parker hydraulic system, IFM controller hydraulic and electric control scheme to ensure quick operation.



XCMG XCS4531T Reach Stacker Optional Configurations:

smart brakes, precise weighing, panoramic images, etc.



Applicable

ISO 20ft standard container

Basic configuration













EngineQSM11

Rated power/speed250kw/2100rpm

Gearbox model:DANA 15.7TE30510

Tyre model18.00-25

Maximum static load150t

Spreader
















modelXDJ450T

Rotation angle+105/-195°

Side shift distance±800mm

Angle of inclination

Weight4.9t

ISO 20ft standard container

Boom assembly




Max. Lifting Height9.2m

Angle of inclination060°

Main Technical Data
















Weight65t

Dimensions:10750*6053/12185*4670mm

Wheelbase6000mm

Minimum ground clearance350mm

Front track3033mm

Rear track2770mm

Technical specifications

























Max. Lifting Capacity45t

Number of Stacking39′6″/8′6″

Maximum lifting speed (no load/ full load)420/250 mm/s

Maximum falling speed (no load/full load)360/360 mm/s

Maximum travelling speed25/21 km/h

Gradeability:39/32%

Minimum turning radius8000mm

20′ Aisle width  A1:11300mm

40′ Aisle width  A1:13600mm



China XCMG 45 ton 9m reach stacker for 20ft container priceChina XCMG 45 ton 9m reach stacker for 20ft container priceChina XCMG 45 ton 9m reach stacker for 20ft container priceChina XCMG 45 ton 9m reach stacker for 20ft container price

China XCMG 45 ton 9m reach stacker for 20ft container price

China XCMG 45 ton 9m reach stacker for 20ft container price

China XCMG 45 ton 9m reach stacker for 20ft container price



More About Container Reach Stacker



China XCMG 45 ton 9m reach stacker for 20ft container priceChina XCMG 45 ton 9m reach stacker for 20ft container priceChina XCMG 45 ton 9m reach stacker for 20ft container priceChina XCMG 45 ton 9m reach stacker for 20ft container priceChina XCMG 45 ton 9m reach stacker for 20ft container priceChina XCMG 45 ton 9m reach stacker for 20ft container price

Send your message to this supplier
Email:
to:
XCMG E-commerce Inc.
Content:
/6000

Your inquiry content must be between 20 to 6000 characters.

Quantity:
/ Set
back to top
Response Time : Within 24 hours
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
