200 ton QAY200 XCMG all terrain crane for sale

  • 200 ton QAY200 XCMG all terrain crane for sale
  • 200 ton QAY200 XCMG all terrain crane for sale
  • 200 ton QAY200 XCMG all terrain crane for sale
  • 200 ton QAY200 XCMG all terrain crane for sale
  • 200 ton QAY200 XCMG all terrain crane for sale
  • 200 ton QAY200 XCMG all terrain crane for sale

Share:
200 ton QAY200 XCMG all terrain crane for sale
FOB for Cranes Reference Price:Get Latest Price
$10000.00-$1000000.00 1 / EA (Min. Order)
Model: QAY200
Engine: VOLVO
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
200 ton QAY200 XCMG all terrain crane for sale
200 ton QAY200 XCMG all terrain crane for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Model Number:QAY200
  • Brand Name:XCMG
  • Place of Origin:Xuzhou,Jiangsu,China
  • Span:8.7m
  • Max. Lifting Height:82.1m
  • Max. Lifting Load:200 ton
  • Rated Lifting Moment:6774kN.m
  • Application:Construction
  • Certification:CE/ISO9001
Specifications
  • weight:71000.000kg
  • Condition:New
  • Moving Type:Wheel
  • Color:Color
  • Engine rated power:390/1800kW/(r/min)
  • Max. travel speed:71km/h
  • Min. turning diameter:24m
  • Engine rated torque:2400/1080N.m/(r/min)
  • Max. grade ability:48%

200 ton QAY200 XCMG all terrain crane for sale

200 ton QAY200 XCMG all terrain crane.



XCMG all terrain crane QAY200 the lifting capacity takes the lead in the industry with strong power, the 6-axle all terrain crane with high intelligent level.



Advantages and highlights:



1. Axle load monitoring technology: Proper gear (the highest gear engaged) and axle driving mode are matched automatically by axle load monitoring technology, which provides protection for crane safety in traveling.



2.  Dynamically choosing different braking modes, which contributes to precise control on power performance and avoids invalid braking control or insufficient braking force, and can shorten emergency braking distance, effectively avoid traffic accident, reduce the abrasion of braking system and increase the service life.



3. The mechanism damage can be avoided  by axles suspending in the air under severe road conditions.



4. With first launched multi-mode drive technology in the industry, real-time intelligent control for various working conditions is realized so that the XCMG all terrain crane QAY200 has optimized travel state and crane safety and reliability are improved.

200 ton QAY200 XCMG all terrain crane for sale

Dimension
Unit
QAY200
Dead weight in travel state
kg
71000kg
Superstructure engine

TAD720VE or TAD750VE
Superstructure engine rated output
kW/(r/min)
162/2100 or 181/2300 kW/(r/min)
Carrier engine

OM502LA. Ⅲ/3
Carrier engine rated output
kW/(r/min)
390/1800 kW/(r/min)
Carrier engine max output
N.m/(r/min)
2400/1080 N.m/(r/min)
Max. travel speed
km/h
71 km/h
Min. turning diameter
m
<=24
Superstructure engine max output
N.m/(r/min)
854/1400 or 1050/1500 N.m/(r/min)
Max. grade ability
%
48%
Fuel consumption for 100km
L
80L
Max. lifting capacity
t
200t
Min. rated working radius
m
3m
Turning radius at swing table tail
mm
5070mm
Parameters Max. load
kN.m
6774 kN.m
Parameters Lifting height
m
14.5m
Full- extended boom Lifting height
m
61.5m
Full-extended boom+ jib Lifting height
m
82.1m
Longitudinal distance Outrigger span
m
9.625m
Lateral distance Outrigger span
m
8.7(6.5)m
Boom elevating time
s
90s
Boom telescoping time
s
550s
Max. swing speed
r/min
1.9 r/min
