XCMG QY25K5A 25 ton truck crane On Sale
FOB for Cranes Reference Price:Get Latest Price
$10000.00-$100000.00 1 / EA (Min. Order)
Model: QY25K5A
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG QY25K5A 25 ton truck crane On Sale
XCMG QY25K5A 25 ton truck crane On Sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
Specifications
  • weight:32800.000kg
  • Wheelbase:4425+1350 mm
  • Total mass in driving state:32800 kg
  • Engine rated power:213/2200 kw/(r/min)
  • Maximum travel speed:90 km/h

XCMG QY25K5A 25 ton truck crane On Sale



XCMG QY25K5A 25 ton truck crane.



XCMG QY25K5A 25 ton truck crane is a cost-effective product that is fully upgraded on the basis of our company's mature QY25K5-I.



Highlights:



1."U"-shaped main boom, industry-leading boom length and lifting performance.



2. Brand-new power transmission platform, leading in driving performance and lowest driving fuel consumption in the industry.



3. Double pump confluence technology, leading the efficiency of luffing and telescopic operation.



4.Technical optimization and improvement, the whole machine operation is safer and more reliable.



5.The newly upgraded appearance and humanized design make the driving operation more comfortable.



XCMG QY25K5A 25 ton truck crane On Sale



Project

Unit

Parameter

Parameter item



QY25K5A

Size parameters



Overall length

mm

12680

Overall width

mm

2500

Overall height

mm

3400

Wheelbase

mm

4425+1350

Weight parameter



Total mass in driving state

kg

32800

Axle load

kg

Front axle 7300/rear axle 25500

Dynamic parameters



engine model



SC9DF290Q4

Engine rated power

kw/(r/min)

213/2200

Engine rated torque

N.m/(r/min)

1200/1400

Driving parameters



Driving



Maximum travel speed

km/h

90

Minimum stable driving speed

km/h

2.53

Turn



Minimum turning diameter

m

22

Minimum turning diameter of arm head

m

29

Maximum grade

41

Minimum ground clearance

mm

275

Approach angle

°

11

Departure angle

°

12

Braking distance

m

≤10

Fuel consumption per hundred kilometers

L

32

Main performance parameters



Maximum rated total lifting capacity

t

25

Minimum rated range

m

3

Maximum lifting moment of basic boom

kN·m

1061

Turntable tail radius of gyration

mm

3255
