HY-260 self loading concrete mixer

  • HY-260 self loading concrete mixer
  • HY-260 self loading concrete mixer
  • HY-260 self loading concrete mixer
  • HY-260 self loading concrete mixer
  • HY-260 self loading concrete mixer

Share:

HY-260 self loading concrete mixer

Chat Now 1 / EA (Min. Order)
Model: HY-260
Engine: Yunnei 76kw engine.
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
HY-260 self loading concrete mixer
HY-260 self loading concrete mixer
Quantity:
- + /EA

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Dimension(L*W*H):6380*2470*2820mm(3630mm)
  • Weight:5800KG

Specifications

  • Weight:5800.000kg
  • Condition:New
  • Moving Type:Other
  • Wheelbase:2600mm
  • Swing Angle :≥60°

Model

Desc

Qty

EXW price



HY250    mobile self loading concrete mixer with 240°rotation function

Yunnei 76kw engine.

Concrete output productivity 2.5 cbm

With 240°rotation function

double reverse camera .

Air conditioner

Automatic weighting system with printer

4 batches per hour.

Hydraulic Torque Converter Transmission,

4 wheel drive ,articulated style.

16/70-20 tyres .

Turbo-Wom rotation .

automatic upper water system ,with pump and pipes.

preheater for engine ,

heater in Cabin ,

warning light, back sound, radio, fan, hand brake, extinguisher, window hammer,  Easy damaged spare parts ,tool box.

1

































Total









Name

Item

Spec

Overall machine

Net weight

5800kg

Overall size

6380*2470*2820mm(3630mm)

Transmission

Full Hydraulic

4WD

Brake

Air brake

Chassis

Off-road

Wheelbase

2600mm

Loader bucket

Capacity

0.3cbm

Control

Hydraulic

Tilt Angle

30%



Speed

High speed

0-25KM/H





Low speed

0-9KM/H

Min turning radius

3.3m/r

Tyre Model

16/70-20

Engine

Type

Yunnei



Rated Power/RPM

76KW/2400RPM

Max Torque/RPM

460N.W/1400RPM

Cylinder

4

Starter

Electric

Cooling type

Water Cooling

Maxing Drum





Drum full capacity

3.5cbm

Drum work capacity

2.5cbm

Bank angle

16°

Self rotation angle

24

Rotation speed

21R/min

Chute

Swing Angle

≥60°

Angle control

Hydraulic

Size

110CM

Loader

Weight model

Computer control

Concrete standard

C15.C20.C25.C30

Accuracy

Cement

≤±2%/time

Relative error

≤±3%/time

Water

≤±1%/time

Additive

≤±1%/time

Admixture

≤±2%/time

Loader control

Hydraulic control 4 way stick
