Aerosun 25000L CGJ5341GJJ Aircraft Refueller

  • Aerosun 25000L CGJ5341GJJ Aircraft Refueller
  • Aerosun 25000L CGJ5341GJJ Aircraft Refueller

Share:
Aerosun 25000L CGJ5341GJJ Aircraft Refueller
CIF/DAT/FOB Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping
Payment Terms:
Aerosun 25000L CGJ5341GJJ Aircraft Refueller
  • Summary
  • Details
Summary
Details
  • Product Name:G5EAA3D9E88B6C
  • Display online time:2020-04-30
  • weight:14600.000kg

Aerosun CGJ5341GJJ Aircraft Refueller

1.Main standard

lQ/3201 CG 1038 Aircraft Refueller

lMH/T 6101 Aircraft Refueller

2.Operating Temperature

Low temperature type: -40 ~ +46

3.Main functions

lPressure refueling: pressure refuel all kinds of aircrafts or other containers from oil tank by its pressure refueling nozzle of reel hose after filtering and measuring.

lGravity refueling --gravity refuel all kinds of aircrafts or other containers from oil tank by its gravity refueling gun of reel hose after filtering and measuring..

lVacuum pumping oil: pumping oil from all kinds of aircrafts to its own oil tank by pressure refueling nozzle after filtering and measuring.

lMixing oil: mix oil in the oil tank.

lMobile pump station.

lElectronic control deadman (it can activate the time control system), beyond deadman.

lTank high and low level control and secondary high level alarm.

4.Entire vehicle technical specification

Model

CGJ5341GJJ

Payload: (kg)

19625

Min. turning diameter: (m)

20

Tank Volume

geometric volume

27050 L

rated volume

25000 L

Refueling flow rate (L/min)

Gravity refueling

300 (single hose)

Pressure refueling

1200 (single hose)

Max. Bottom Loading Flow Rate (L/min)

1500 (single hose)

Max. De-fueling Flow Rate (L/min)

300 (single hose)

Accuracy of Flow mete

±0.1

Tank Material

Aluminum Alloy 5083,6mm

Closing pressure of refueling nozzle

345±50KPa

Pressure reel hose

DN63*25m

Gravity reel hose

 DN38*15m

Filter Separator Standard

Comply with EI 1581 5th
