Best quality 200KW XHZ Cummins Diesel generator set XHZC-200GF price

Chat Now 1 / EA (Min. Order)
Model: XHZC-200GF
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
Best quality 200KW XHZ Cummins Diesel generator set XHZC-200GF price

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

Specifications

  • Weight:1200.000kg
  • Condition:New
  • Type:Open Frame
  • Engine Brand:Cummins
  • Power Range:10-200KW
  • Rated Power:200KW/250KVA
  • Rated voltage:400/230 V

One the main parameters of the set

The model of the unit

XHZC-200GF

Rated Power

200KW/250KVA

Standby power

220KW/275KVA

Rated voltage

400/230 V

Rated current

361A

Frequency/Speed

50Hz/1500RPM

The waste of fuel with full load

199g/kw.h

Engine specification

Engine

Cummins

Brand

DCEC

Model

6LTAA8.3-G2

Rated Power

220KW/275KVA

Standby power

240KW/300KVA

No. of Cylinders

6

Type

4 cycle

Aspiration

Turbocharged and Charge Air Cooled

Standby power

50Hz/1500RPM

Bore*Storke:

114 *145MM

Displacement

8.3L

Compression Ratio

16.6:1

Lubricating oil capacity

28L

Cooling system

40L

Starting way

      DC24V starting with electricity



Alternator specification

Brand

XHZ

Place of production

Jiangsu

Model

WXHZ-200

Type

brushles

The connecting way of the phase

three phase four lines

Frequency/Speed

50Hz/1500RPM

Insulation degree

H degree

Grading Protection

IP23

Winding connection

Star

Voltage regulator type

AVR

Bearing

Single Bearing

Coating

Vacuum impregnation

coupling

Flexible disc

Control system introduction

Brand

             Smartgen

Place of production

             ZhengZhou

Model

           HGM6110series

HGM6110series automatic controller, integrating digital, intelligent and network techniques, is used for automatic control and monitoring system of single genset. It can carry out functions of automatic start/stop, data measurement, alarm protection and “three remote” (remote control, remote measurement and remote communication). The controller uses LCD display, optional language interface including Chinese, English, Spanish, Russian, Portuguese, Turkish, Polish and French with easy and reliable operation.

HGM6110series automatic controller uses micro-processing technique which can achieve precision measurement, value adjustment, timing and threshold setting etc. All the parameters can be configured from front panel or use USB interface (or RS485 interface) to adjust via PC. It can be widely used in all types of automatic control system for its compact structure, simple connections and high reliability.

Best quality 200KW XHZ Cummins Diesel generator set XHZC-200GF price

Mains

Generator

Line voltage (Uab, Ubc, and Uca)

Line voltage (Uab, Ubc, and Uca)

Phase voltage (Ua, Ub, and Uc)

Phase voltage (Ua, Ub, and Uc)

Frequency HZ

Frequency HZ

Voltage regulator type

AVR

Load

Current IA, IB, IC

Active power KW

Reactive power KVar

Apparent power KVA

Power factor PF

Generator accumulated energy kWh

Mains have functions of over/under voltage and lack of phase; Gens have functions

of over/under voltage, over/under frequency and over current;

Precision measure and display of parameters about engine

Temp. (WT)

°C/ °F both are displayed

Oil pressure (OP)

kPa/Psi/Bar are all displayed

Fuel level (FL)

%

Speed (SPD),

RPM

Battery Voltage (VB)

V

Charger Voltage (VD)

V
