XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

  • XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China
  • XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China
  • XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China
  • XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China
  • XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

Share:
XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China
FOB for Loader Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: LW156FV
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China
XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
Summary
  • Rated Load:1100kg
  • Dimension(Long* Breadth * High):6140*2060*2900mm
  • Type: front loader
  • Place of Origin: Jiangsu, China
  • Model Number: LW156FV
  • Brand Name: XCMG
  • Certification: CE/ISO9001
Details
  • Product Name:G5FE3087A173A7
  • Display online time:2021-02-04
  • weight:4550.000kg
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Warranty:12 Months
  • Engine Brand:SHANGCHAI
  • Rated Load:1-3 ton
  • Bucket Capacity:0-1m³

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV.



LW156FV is equipped with national two-stage engine, high-quality split type double change, four-wheel drive, full hydraulic steering, strong power, higher efficiency and stronger environmental adaptability. The replacement period of the hydraulic oil is extended to be 2000h, which is far beyond the same industry level and greatly reduces the using cost.



Performances and specialties:

1. The replacement period of the hydraulic oil is extended to be 2000h, which is far beyond the same industry level and greatly reduces the using cost.





2. The unloading height is more than 3m, which meets all kinds of operation. As the overall oil cylinder and pin is tempered and quenched, the hardness leads in the industry and its reliability is high.

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

Item

Short boom

Standard boom

Long boom

Units

Rated load

1200

1100

1000

kg

Tipping load

2400

2200

2000

kg

Unloading height

Bucket flat height

3470

3740

3870

mm

Standard

3000

3300

3500

mm

Unloading distance

785

830

1070

mm

Rated bucket capacity



0.7



m3

Overall mass

4450

4550

4650

kg

Wheel base



2300



mm

Tread



1500



mm

Maximum hoisted hinge pin height

3730

3920

4190

mm

Maximum breakout force



44



kN

Maximum traction



40



Boom hoisting time



5.5



s

Three items and time



9



s

Minimum turning radius (tire center)



4620



mm

Articulation angle



35



°

Climbing capacity



25



°

Minimum ground clearance



260



mm

Tire specification



16/70-16



-

Overall dimensions (length*width*height)

5890*2060*2900

6140*2060*2900

6390*2060*2900

mm

Engine

Model



YN27GBZ



-

Rated power/speed



55/2400



kW/rpm

Driving speed

First positin (drive/back)



8



km/h

Second position (drive/back)



20.5



km/h

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China



uMore wheel loader





XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China

XCMG Official 1 ton articulating mini wheel loaders machine LW156FV made in China
