XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price

  • XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
  • XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
  • XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
  • XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
  • XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
  • XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price

Share:
XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
FOB for Mining Mach Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: XE280E
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
Specifications
  • weight:280000.000kg
  • Condition:New
  • Moving Type:Other
  • Bucket capacity:15m3
  • Maximum Digging Depth:3800mm
  • Maximum Digging Height:15660mm
  • Operating Weight:280000kg
  • Brand Name:XCMG
  • Place of Origin:China

XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price

XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E.



The XE series of large mining hydraulic excavators bring you an extraordinary driving experience with lean manufacturing, professional design and excellent reliability. Moreover, this series of products boast strong excavating power and quick operating speed, making them have matchless operating performance and economic efficiency even in severe mining condition.



1. 6Kv high pressure motor drive with zero emission is environmental friendly.

2. Electric control positive flow hydraulic system is high efficient and energy saving.

3. Hydraulic buffering technology can realize realtime protection for crawler during travel.

4. Closed swing system is adopted to achieve more stable rotation and energy saving.

5. Fully closed floating axle pins and mining heavy-load working device.

6. Automatic lubrication system of whole machine has high lubrication efficiency.

7. Al-terrain concentrated fling system, maintenance is convenient and fast.

XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price

Description

Parameter

Unit

Operation weight

280000

kg

Bucket capacity

15

Model

MGF500A



Output power

1200/1490

kw/rpm

Traveling speed

2.0/1.5

km/h

Rotary speed

4

r/min

Grade ability

30

°

Ground pressure

195

kPa

Bucket digging force

935

Kn

Arm digging force

1200

Kn

Main pump

4 plunger pumps



Rated flow

4x720

L/min

Main safty valve pressure

32

MPa

Standard configuration

Length of boom

6370

mm

Length of arm

4200

mm

Bucket capacity

15

m3

Apperance size

Total lengtk

19976

mm

Length of crawler

8108

mm

Wheel base of crawler

6420

mm

Ground clearance of counter wehight

2247

mm

Total height

7481

mm

Total width

8539

mm

Track gauge

4900

mm

Width of crawler

1000

mm

Height of crawler

2165

mm

Working scope

Max. digging height

15660

mm

Max. dumping height

10300

mm

Max. digging depth

3800

mm

Max. horizontal clearance distance

3800

mm

Min. horizontal clearance distance

8628

mm

Max. digging radius

13880

mm

Min. swing radius

8800

mm

Min. horizontal scratching radius

6600

mm

Max. opening dimension of bucket

2200

mm

XCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E PriceXCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E PriceXCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E PriceXCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E PriceXCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E PriceXCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E PriceXCMG Mining Heavy Duty Excavator Hydraulic Crawler 280 Ton Equipment Excavators XE2800E Price
