China 8 - 10 ton HOWO Mounted Crane for sale
Summary
- Brand Name:XCMG
- Place of Origin:XUZHOU,CHINA
- Max. Lifting Load:10ton
Specifications
- weight:10000.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
China 8 - 10 ton HOWO Mounted Crane.
China 8 - 10 ton HOWO Mounted Crane: HOWO extended cab. Basic configuration is single berth; New seats; Up and down, front and rear adjustable steering wheel; European-style integral heater; The German VDO instrument synchronizing with the world high-grade heavy card;
1. Highway vehicles are four-point full-floating suspension (front coil spring, rear air spring) + shock absorption device.
2. Non-highway vehicles are four-point full-floating spring suspension + shock absorption device.
China 8 - 10 ton HOWO Mounted Crane Highlights:
-Single cylinder synchronization guy cable technology make work efficiency more higher than before.
-Advanced development means make sure that the design is very reliable.
-The more symmetrical center design of pentagon & hexagon boom make it has bigger anti-bending capacity.
-Compact Hinge point design take up smaller space.
-The work is more safety after fitted with overwind alarm equipment.
-The integer lifting winch improved the work efficiency greatly and prolonged work life of hydraulic system.
-Float three-point bridge structure design can lower the accessional stress on the chassis when traveling.
-Self-designed & developed slewing machine with greater drive force can meet varied requirements of working situation.
-Anti-slewing impulse equipment make vehicle running safely.
|
Item |
Unit |
SQ8SK3Q |
SQ10SK3Q |
SQ12SK3Q |
SQ16SK4Q |
|
Max.Total Rated Lifting Load |
T |
8 |
10 |
12 |
16 |
|
Max. Lifting Height |
M |
13.2 |
14 |
14.7 |
18.5 |
|
Max.lifting moment |
T.M |
20 |
25 |
30 |
43.2 |
|
Max.lifting capacity |
KG |
8000 |
10000 |
12000 |
16000 |
|
Max.hydraulic outreach |
M |
11.5 |
12 |
12.5 |
18.5 |
