XCMG 1.5ton 4 wheel Electric Forklift FB15-AZ1 for sale

Share:
XCMG 1.5ton 4 wheel Electric Forklift FB15-AZ1 for sale
FOB for Cranes Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Shipping
Payment Terms:
XCMG 1.5ton 4 wheel Electric Forklift FB15-AZ1 for sale
  • Product
  • Summary
  • Details
Product
Summary
  • Model Number:FB15-AZ1
  • Brand Name:XCMG
  • Place of Origin:China
  • Span:Longitudinal6.1m/Lateral7.1m
  • Max. Lifting Height: 4055mm
  • Rated Loading Capacity:1500
  • Application:Construction Industry
  • Certification:ISO9001/CE
Details
  • Product Name:G5CDBDE4B6E006
  • Display online time:2019-11-14
  • weight:42200.000kg
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Warranty:12 Months
  • Condition:NEW
  • Moving Type:wheel
  • Min. Lifting Height:2025mm
  • Overall Dimensions:2150*1090*2025mm


XCMG 1.5ton 4 wheel Electric Forklift FB15-AZ1 for sale

• Full AC System
• OPS System
• Comfortable Operator Space
• Side-way Battery Change System
• Lower Energy Consumption and Energy Regeneration Function
• Easy-to-read operator display
• Front Dual AC Motor Traction System
• World Class Gear Box System
• Automatic Maintenance Alarm
• Zero-Emission,Zero-Pollution,Low-Level Vibration,Low-Level Vibration,Low Operation Cost, High Efficiency ,High Quality,these are the reasons for you to choose a XCMG Electric Forklift.
• The Energy Regeneration Function extend extra 15% working hours,which provide the possibility for your tough and long-time working condition.



Model



FB15-AZ1

Rated Load Capacity

Q(kg)

1500

Load Centre

C(mm)

500

 Lift Height

H3(mm)

3000

Free Lift

H2(mm)

100

Fork Size(L×W×T)

mm

920*120*35

Mast Tilt Angle(F/R,α°/β°)

deg

6°/12°

Length(to fork face)

L1(mm)

2150

 Width

B1(mm)

1090

Mast Lowered Height

H1(mm)

2025

Mast Extended Height(with backrest)

H4(mm)

4055

Overhead guard Height

H5(mm)

2125

Turning Radius

Wa(mm)

1995

Fork overhang(Weel center to fork face)

X(mm)

409

Front tread

B2(mm)

890

Rear Tread

B3(mm)

920

Ground Clearance

H6(mm)

110

Wheelbase

Y(mm)

1380

Fork speed(Min/Max)

mm

240/970

Travel Speed(Full load)

Km/h

12

Travel Speed(No load)

Km/h

13

Lifting Speed(Full load)

mm/sec

280

Lifting Speed(No load)

mm/sec

380

Total Weight(Include Battery Box)

kg

3060

Tyre(Front×2)



6.50-12-12PR

Tyre(Rear×2)



5.00-8-8PR

Drive Motor

Kw

7.5

Pump Motor

kw

9.2

Battery(Standard)

V/Ah

48/450

Controller Type



AC

Controller Manufacturer



ZAPI

Operating

Mpa

14.5
