XCMG 2013 year Used Rotary Drilling Rig XR360 price
Specifications
- weight:90000.000kg
- Drilling Depth:Max.102m
- Voltage:220V/380V
- Dimension(L*W*H):18880*3500*3820mm
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 2013 year Used Rotary Drilling Rig XR360 price
It adopts dedicated hydraulic retractable crawler chassis and heavy slewing bearing and has high stability.
The imported Cummins turbo-supercharged engine is powerful, and has sufficient power reserve.
The machine adapt single row rope for main winch to figure out the wear of steel rope. extend the life-span. And
high reliability.
The oil cylinder and sleeve-driven functions are available for selection to satisfy various needs of the users.
Normal mode and entering-rock mode of unit head are available for operation in soil and rock to improve the
construction efficiency.
It is equipped with a centralized lubrication system as standard configuration; maintenance is easy.
Uncased | (mm) | φ2500 |
Cased | (mm) | φ2200 |
Max.Drilling Depth | (m) | 102 |
Dimension | ||
Working condition L × W × H | (mm) | 11000X4800X24586 |
Transportation condition L × W × H | (mm) | 18880×3500×3820 |
Overall Drilling Weight | (t) | 90 |
Engine | ||
Model | - | CUMMINS QSM11-C400 |
Rated Power | (kW) | 298/2100 |
Hydraulic System | ||
Working pressure | (MPa) | 33 |
Rotary Drive | ||
Max. output torque | (kN.m) | 360 |
Rotary speed | (r/min) | 6~25 |
Spin off speed | (r/min) | - |
Pull-Down Cylinder | ||
Max.pull-down piston push | (kN) | 240 |
Max.pull-down piston pull | (kN) | 250 |
Max.pull-down piston stroke | (mm) | 6000 |
If any other questions, please feel free to contact with us.
