XCMG 220 ton all terrain mobile crane XCA220H

  • XCMG 220 ton all terrain mobile crane XCA220H
  • XCMG 220 ton all terrain mobile crane XCA220H
  • XCMG 220 ton all terrain mobile crane XCA220H
  • XCMG 220 ton all terrain mobile crane XCA220H
  • XCMG 220 ton all terrain mobile crane XCA220H
  • XCMG 220 ton all terrain mobile crane XCA220H

XCMG 220 ton all terrain mobile crane XCA220H

XCMG 220 ton all terrain mobile crane XCA220H
XCMG 220 ton all terrain mobile crane XCA220H
XCMG 220 ton all terrain mobile crane XCA220H
XCMG 220 ton all terrain mobile crane XCA220H
XCMG 220 ton all terrain mobile crane XCA220H
XCMG 220 ton all terrain mobile crane XCA220H
XCMG 220 ton all terrain mobile crane XCA220H

XCMG 220 ton all terrain mobile crane XCA220H

FOB Price: $10000.00-$100000.00
View All >
Model: XCA220H
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG 220 ton all terrain mobile crane XCA220H
XCMG 220 ton all terrain mobile crane XCA220H
Quantity:
- + /Unit

Content:

Or choose from these questions:
What is the best price you can offer?
Do you support customization?
What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

XCA220H
Specs & Compare
Details
Specs & Compare
Select 3 models for comparison
Model Number
Brand Name
Place of Origin
Span
Max. Lifting Height
Max. Lifting Load
Rated Lifting Moment
Rated Loading Capacity
Application
Certification
Engineering & Construction Machinery
XCA220H
XCA220H
XCMG
Jiangsu, China
360
73.5m
220T
7393kN.M
220T
Construction works
CE ISO9001
+   Add a Product
+   Add a Product

Summary

  • Model Number: XCA220H
  • Brand Name:XCMG
  • Place of Origin:Jiangsu, China
  • Span:360
  • Max. Lifting Height: 73.5m
  • Max. Lifting Load:220T
  • Rated Lifting Moment:7393kN.M
  • Rated Loading Capacity:220T
  • Application:Construction works
  • Certification:CE ISO9001

Specifications

  • weight:2200000.000kg
  • Condition:New
  • Moving Type:Other
  • Color:Red

Packaging & Shipping

  • Delivery Lead Time:7 days for ready goods
  • Minimum Order:1 Piece
  • Supply Ability:10,000 Set/ Sets per Month
  • Total Quantity In Stock:Over 5000
  • Delivery Port:Any Port In China



XCMG 220 ton all terrain mobile crane XCA220H

(1)XCA220H is a five-axle 220 t all terrain crane with leading lifting performance, widely used for the lifting operations in general engineering projects, such as construction site, urban renewal, transportation, ports, bridges, oilfields, mines, etc.



(2)Efficient jobsite transfer, convenient and economical: the travel speed is 80 km/h for long distance jobsite transfer; low speed large torque driveline is adopted and the fuel consumption per 100 km is 70 L; low cost for long distance jobsite transfer; there is no need for auxiliary crane for short distance jobsite transfer. 72 t counterweight, auxiliary winch, hook, outriggers, outrigger floats, spare tire, etc. can be carried on board. The jobsite transfer is highly efficient with low cost.



(3)Intelligent control saves time and money: industry-leading intelligent crane boom technology is adopted to provide the most intelligent operation planning and safety protection; innovative multi-mode drive technology combined with axle load detection technology provides double protection for crane traveling safety.



(4)The comprehensive performance is 15% higher than that of competing products.



(5)Single engine, reduced weight, improved performance.



(6)Seven-section boom can be extended to 72 m, fixed jib of 44 m; offset angles of 0°, 20° and 40°; the max. boom+jib can reach 107.3 m.



(7)The max. load moment: 6664KNm.



(8)the total weight of counterweight is 72 t.



(9)Diesel engine, Max. net power of 397kw, and the max. output torque of 2500N.m.



(10)The max. travel speed is 80 km/h, and the max. grade ability is 67%.



(11)6 steering modes.





Category

Item

Unit

Parameter

Dimensions

Dimensions (length×width×height)

mm

15350×3000×3950

Wheel base

mm

2650+1650+2900+1650

Track (Front/ Rear)

mm

2590/2590/2590/2590/2590

Front/ Rear overhang

mm

2664/2245

Front/ Rear extension

mm

1591/0

Weight

Max. permissible weight

kg

54990

Axle

load



1st axle

kg

11650

 2nd axle

kg

11650

3rd axle

kg

11650

4th axle

kg

10020

5th axle

kg

10020

Rated power/rpm

kW/(r/min)

400/1900

390/1900

Max. output torque/rpm

N.m/(r/min)

2500/1050~1350

2500/1000~1400

Travel

Travel

speed

Max. travel speed

km/h

≥80

Min. stable travel speed

km/h

11.5

Turning

diameter

Min. turning diameter

m

≤18.5

Min. turning diameter at boom tip

m

≤22.5

Min. ground clearance

mm

300

Approach angle

°

18

Departure angle

°

14

Braking distance (at 30 km/h)

m

≤10

Max. grade ability

%

60

Fuel consumption per 100 km

L

72

Exterior noise level

dB(A)

≤88

Noise level at seated position

dB(A)

≤90

Main     performance

Max. total rated lifting capacity

t

220*

Min. rated working radius

m

3

Turning radius at turntable tail

Counterweight

mm

5100

Auxiliary winch

mm

4883

Max. load moment

Base boom

kN.m

6664

Fully-extended boom

kN.m

2587

Fully-extended boom + Jib

kN.m

1123

Outrigger span

Longitudinal

m

9.19

 Lateral

m

8.3

Hoist height

Base boom

m

13.4

Fully-extended boom

m

72

Fully-extended boom + Jib

m

107

Boom length

Base boom

m

13.3

 Fully-extended boom

m

72

Fully-extended boom + Jib

m

107.3

Jib offset angle

°

02040

Hoisting speed (single line, 4th layer, no load)

Main winch

m/min

≥130

Auxiliary winch

m/min

≥130

Noise

Exterior noise level

dBA

≤122

Noise level at seated position

dBA

≤85
