XCMG China Hydraulic Rough Terrain Crane 25ton XCR25L5 for Sale

Chat Now 1 / EA (Min. Order)
Model: XCR25L5
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG China Hydraulic Rough Terrain Crane 25ton XCR25L5 for Sale

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Model Number:XCR25L5
  • Brand Name:XCMG
  • Place of Origin:China
  • Max. Lifting Height:46.6 m
  • Max. Lifting Load:25 Ton
  • Rated Lifting Moment:931/1400 kn.m
  • Rated Loading Capacity:25 Ton
  • Application:all
  • Certification:CE

Specifications

  • Weight:25000.000kg
  • Condition:New
  • Moving Type:Other
  • Weight (KG):25000 kg
  • Min. rated working radius:3 m

XCMG China Hydraulic Rough Terrain Crane 25ton XCR25L5 for Sale

XCMG China Hydraulic Rough Terrain Crane 25ton XCR25L5 for Sale.

XCR25L5 is equipped with the two-axle loading chassis, which has two types of drive modes, four types of steering modes and backward-forward driving functions. It also has four sections of dodecagon main booms, Jib stowed under boom, H type outrigger, fixed balance counterweight, as well as three working modes, including: hoisting with the support of outriggers, hoisting with the support of tire and hoisting when driving. It is widely used in oil field, mine, road and bridge construction, warehousing base and other construction sites.

1. High mobility and efficiency
* Two driving types of 4×2 and 4×4 are adopted with forwards and backwards driving function.
* Four steering modes are adopted , and the min. turning radius is 5.0m with better job site adaptability.
* Due to powerful power configuration, specific off-road tires and all-wheel drive, the crane can easily handle various tough
terrains.

2. Powerful lifting capacity
* Single-cylinder plus ropes telescoping system, stable and reliable.
* 4-section boom of 31m and jib of 13m with wide operation range.

3. Energy-saving and environmental friendly
* The torque converter with lockout function has features of large torque at low speeds and high efficiency at high speeds.
* Elevating control system for freefall, without additional power needed.

4. High safety
Dedicated traveling safety protection system is adopted, which can realize classified and graded management for various abnormal

information, and automatic warning, speed-limiting and braking with improved active driving safety.XCMG China Hydraulic Rough Terrain Crane 25ton XCR25L5 for Sale

Dimension
Unit
XCR25L5
Overall length
mm
12202
Overall width
mm
2850
Overall height
mm
3495
Weight
Total weight in travel
kg
28357
Power
Engine model

QSB6.7-C190-3.0
Engine rated power
kW/(r/min)
142/2200
Engine rated torque
N.m/(r/min)
931/1400
Travel
Max. travel speed
km/h
≥40
Min. turning diameter
m
≤9.8
Min. ground clearance
mm
413
Approach angle
°
19.1
Departure angle
°
19.3
Max. grade ability
%
≥90
Main performance
Max. rated total lifting capacity
t
25
Min. rated working radius
m
3
Turning radius at turntable tail
m
3.823
Max. lifting torque
kN.m
901.6
Full-extend boom
m
39.5
Full-extend boom+jib
m
46.6
Boom length
m
48.3
