XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

  • XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
  • XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
  • XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
  • XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
  • XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
  • XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

Share:
XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
FOB for Concrete Mach Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: G08K
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
  • 360-degree VR videos
Summary
  • Dimension(L*W*H):8935x2500x3890mm
  • Weight:14000kg
  • Model Number:G08K
  • Brand Name:XCMG
  • Place of Origin:China
  • Power Type:Diesel
  • Type:Concrete Truck Mixer
  • Certification:CE/ISO9001
Details
  • Product Name:G60474ACCD24E5
  • Display online time:2021-03-09
  • weight:14000.000kg
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Warranty:12 Months
  • Condition:NEW
  • Moving Type:wheel
  • Geometric volume:13.6m³
  • Max. diameter of drum:2250mm
  • Drum length:4820mm
  • Mounting tilt angle:13.5°
  • Rotary speed:0~14r/min
  • Charging speed:≥3m³/min
  • Discharging speed:≥2m³/min
  • Residual ratio of discharging:<1%
  • Range of slump:5~21cm
  • Volume of water tank:450L

XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

XCMG Manufacturer G08K 8cbm Cheap Cement Mixers.



1, On the basis of in-depth and integrative research on the industry, the XCMG new generation truck mixers are system optimized by taking the integrated modularization design to truly realize the integrated innovation.



2,Particular mixing technology with continuous trace, original double log spiral technology with changeable lift angle and changeable screw pitch and optimized auxiliary blades and pressure-reducing hole design can make the operation path of the spiral in perfect state and can ensure the best concrete flowing trend in mixing drum and more uniformly discharging. It can effectively solve the blocking problems in concrete pumps caused by nonuniform concrete.



3, Optimized chassis matches with upper parts and such parts as front base and accessory beam, rear base and tilted beam, rear base and accessory beam adopt integration design.



4, Hydraulic pump, motor and speed reducer of such world-famous brands as ZF, Rexroth, Bonfiglioli, PMP, TOP are adopted to make the power more sufficient, system steadier and more reliable and service life longer.

XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

Catagory

Item

Unit

Parameter

Overall Parameter

Model



G08K

Curb weight

kg

14000

Max.total weight

kg

25000

Outline dimension (L×W×H)

mm

8935×2500×3890

Chassis

Chassis brand



Sinotruk

Chassis model



ZZ1257N3641W

Steering position



LHD

Driving type



6×4

Wheel base

mm

3625+1350

Tire



10.00R20

Power take-off



Flywheel

Engine

Model



WD615.69

Max.power

kW

247

Displacement

L

9.726

Emission standard



Euro II

Drum system

Geometric volume

13.6

Agitating volume

8

Max.diameter of drum

mm

2280

Mixing drum length

mm

4795

Slanting angle

°

15

Rotating speed

r/min

0~14

Feeding speed

m³/min

≥3

Discharge speed

m³/min

≥2

Discharge residual rate

%

< 0.4

Slump scope

mm

50~210



XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale

XCMG Manufacturer G08K 8cbm Cheap Cement Mixers for Sale
