XCMG Drilling Rig XR150D 20m Small Rotary Drilling Rig Price
FOB for Piling Mach Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: XR150D
Engine: Cummins
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Drilling Rig XR150D 20m Small Rotary Drilling Rig Price
XCMG Drilling Rig XR150D 20m Small Rotary Drilling Rig Price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Certification:CE/ISO9001
  • Dimension(L*W*H):13610*2960*3040mm
  • Weight:48000kg
  • Power(W):133kw
  • Voltage:220V/380V
  • Model Number:XR150D
  • Brand Name:XCMG
  • Place of Origin:Jiangsu,China
  • Power Type:Diesel
  • Type:Rotary Drilling Rig
Specifications
  • weight:48000.000kg
  • Condition:New
  • Moving Type:Other
  • Max. drilling diameter:800mm
  • Max. drilling depth:20m
  • Max. extraction force:400kN
  • Max. output torque:150kN.m

XCMG Drilling Rig XR150D 20m Small Rotary Drilling Rig Price

XCMG Drilling Rig XR150D 20m Small Rotary Drilling Rig.



XCMG drilling rig XR150D stands for our company's achievement in many years' development and researches on piling machine, adopting the advanced technology, both at home and abroad. With our company's powerful machinery manufacturing capacity, it is specially designed to drill the pile hole with the big diameter and into hard—layers, fitting for layer conditions in most areas.



Performance Characteristics:

1. It adopts the dedicated hydraulic retractable crawler chassis and large diameter slewing bearing to provide extraordinary stability and transport convenience.



2. It adopts the Cummins electric control turbo-supercharged engine to provide strong power and conformity with Euro III emission standard.



3. With the hydraulic pressure system adopted threshold power control and negative flow control, the system acquired high efficiency and higher energy conservation.



4. Using single rope winding, effectively solve the steel wire rope wear problem, improve the life of wire rope; And drill deep detection device is settled in main winding, single rope to make deep inspection more accurate.



5. The whole machine design meets the requirements of the CE directive, safety guarantee, construction safer.

XCMG Drilling Rig XR150D 20m Small Rotary Drilling Rig Price

Model

Unit

XR150D

Engine

Rated power

kW

133

Power unit

Max. output torque

kN.m

150

Rotate speed

r/min

6~28

Max. drilling diameter

mm

800

Max. drilling depth

m

20

Max. extraction force

kN

400

Main winch

Max. winch speed

m/min

75

Diameter of steel rope

mm

28

Vice winch

Max. elevation force

kN

50

Max. winch speed

m/min

60

Drilling mast Inclination

Lateral

°

3

Chassis

Max. walking speed

km/h

3.2

Max gradeability

%

40

Min. ground clearance

mm

352

Track shoe width

mm

800

Track shoe's largest overall width

mm

2960-4100

Hydraulic system

Working pressure

Mpa

32

Machine working quality/Transporation quality

t

48/43

Boundary dimension

Working condition

mm

8620*4100*22845

L*W*H

Transporation condition

mm

13610*2960*3040
