> XCMG ELECTRIC DRIVE DUMP TRUCK XDE130
- Summary
- Details
Summary
- Dimension(L*W*H）:11825*6790*3860mm
- Weight:205000 kg
- Power(W):899kW/1900r/min
- Max. Speed:50 km/h
- Loading Height:4650 mm
- Model Nubber:XDE130
- Brand Name:XCMG
- Certification:CE/ISO9001
- Place of Origin:China
Details
- Product Name:G5CEE5B854E0D0
- Display online time:2019-11-14
- weight:2050000.000kg
- After-sales Service Provided:Engineers available to service machinery overseas
- Warranty:12 Months
- Condition:NEW
- Moving Type:wheel
- Wheelbase:4900 mm
- Front axle:42500 kg
- Max.grade-ability:20%
- Fuel tank:1200L
- Cooling system:330L
XDE130 electric drive dump truck is mainly used for open pit mining and large-scale earthwork construction. The product has large bearing capacity, resistance to bumps and impact, and has the characteristics of high transportation efficiency, comfortable operation, low maintenance cost and long service life. It is the best choice for the procurement of construction equipment in open pit mines.
Drive type | / | 4×2 | |
Tire | / | 33.00R51 | |
Driving Parameters | Max.vehicle speed | Km/h | 50(XCMG) 50(XCMG electrical drive) |
Min.turning diameter | m | 23 | |
Max.grade-ability | % | 20 | |
Min.ground clearance | mm | 566 | |
Working Parameters | Loading Height | mm | 4650 |
Lifting time | s | 16 | |
Maintenance capacity | Fuel tank | L | 1200 |
Hydraulic tank | L | 650 | |
Cooling system | L | 330 | |
Engine oil | L | 120 | |
Gear oil tank(single) | L | 50 | |
Body capacity | Standard 2:1 stacking | m³ | 60 |
Response Time : Within 24 hours
