XCMG manufacturer 170hp motor grader GR1605 china new grader motor road construction price

$60000.00-$70000.00 1 / EA (Min. Order)
Model: GR1605
Engine: Cummins
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG manufacturer 170hp motor grader GR1605 china new grader motor road construction price

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications
  • 360-Degree VR Videos
  • Product PDF

Summary

Specifications

  • Weight:12500.000kg
  • Condition:New
  • Moving Type:Other

XCMG manufacturer 170hp motor grader GR1605 china new grader motor road construction price

XCMG manufacturer 170hp motor grader GR1605 china new grader motor road construction.



GR1605 is mainly used for large ground surface leveling, ditching, slope scraping, bulldozing, scarifying, snow removing and other work in highway, airport and farmland. The grader is necessary engineering machinery for national defense construction, mine construction, urban and rural road construction, water conservancy construction and farmland improvement, etc.



Performance Characteristics:

1. Uses Cummins turbocharged diesel engine. Large output torque and power reserve coefficient and low oil consumption.



2. Torque converter has big torque ratio, high efficiency and wide high efficiency area. Better combined work characteristics can be achieved when the torque converter is matched with engine.



3. Gears will be easily shifted by electrohydraulic control. During gear shift process, there is no impact, speed ratio distribution is reasonable, and various work requirements can be satisfied.



4. The rear axle adopts balanced suspension to ensure the uniform load of four wheels, which is conducive to the full use of its adhesion ability. The main drive of the rear axle is equipped with“NO - SPIN" self-locking differential.

XCMG manufacturer 170hp motor grader GR1605 china new grader motor road construction price

Item

GR1605

Basic parameters

Engine model

QSB5.9

Rated power/speed

125kW/2200rpm

Overall dimension (standard)

8711x2483x3385

Total weight (standard)

12500 kg

Tire specification

14.00-24

Ground clearance (front axle)

586mm

Tread

2113mm

Space of front and rear axles

6279 mm

Space of middle and rear wheels

1568 mm

Performance parameter

Forward velocity

5,8,13,18,30,47km/h

Reverse speed

5,13,30km/h

Tractive effort f=0.75

≥70 kN

Maximum gradeability

≥25%

Tire inflation pressure

260kPa

Working system pressure

22MPa

Transmission pressure

1.3-1.8Mpa

blade

Maximum lift height

410mm

Maximum cutting depth

715mm

Maximum tilt angle

90°

Cutting angle

29°-69°

Angle of revolution

360°

Length & chord height

3965x610mm

Oil filling amount

Coolant

50L

Fuel tank

380L

Engine

24L

Transmission

38L

Equilibrium box

60L

Coolant

36L

Hydraulic oil

170L
