XCMG 215hp Road Grader Motor Machine China New Motor Grader GR2153 For Sale
Specifications
- Weight:16500.000kg
- Condition:New
- Moving Type:Other
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Certification:CE/ISO9001
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG 215hp Road
Grader Motor Machine China New Motor Grader GR2153 For Sale.
The motor grader is mainly
used for ground leveling, ditching, slope scraping, bulldozing, scarification,
snow removal for large areas such as highway, airports, farmlands etc. It is
the necessary construction machinery for national defense construction, mine
construction, urban and rural road construction and water conservancy
construction, farmland improvement and so on.
1. Energy saving and noise reduction: adopt low
speed engine transmission line, low fuel consumption and energy saving and
environmental protection; The transmission system is equipped with low speed
ratio, and the average fuel consumption is reduced by about 8%. Three levels of
engine, cab and seat vibration reduction; The cab is supported by six points;
Deceleration of engine, cooling fan with large diameter, sound absorption
sponge inside the hood, good sealing of the cab reduces noise of the whole
machine.
2. Strong power: Shangchai efficient China stage I
engine and hydraulic torque converter, the optimal torque converter achieves
the best matching of torque converter and engine, reducing the start time,
increase the work of torque output at low speed, strong and powerful. The
optional herringbone tread tires, the adhesion can be increased by 10% in loosing
soil and leveling, further enhance the power output.
3. Rotation with load: improve the pressure of hydraulic system system,
the rotary force of the blade, the high frequency quenching treatment improves
the wear resistance and life span, and realize the rotation operation.
4. Efficient operation: improves the displacement
of hydraulic pump and hydraulic motor, increase the oil cylinder speed by 20%,
realizes the industry leading work efficiency, the optimized blade shape can
turn and remove the soil quickly and efficiently, and realize optimal load
distribution and the minimum material accumulation within the rotary discarea.
|
|
Item |
Unit |
GR2153 |
|
|
Basic parameters |
Engine model |
|
QSB6.7 |
|
|
Rated
power/speed |
kW/rpm |
164/2000 |
||
|
Overall
dimension(standard) |
mm |
8970 x 2625 x
3420 |
||
|
Total
weight(standard) |
kg |
16500 |
||
|
Tire
specification |
|
17.5-25 |
||
|
Ground clearance |
mm |
430 |
||
|
Tread |
mm |
2156 |
||
|
Space of front
and rear axles |
mm |
6219 |
||
|
Space of middle
and rear wheels |
mm |
1538 |
||
|
Performance
parameters |
Forward velocity |
km/h |
5、8、11、19、23、38 |
|
|
Reverse speed |
km/h |
5、11、23 |
||
|
Tractive effort
f=0.75 |
kN |
≥85 |
||
|
Maximum
gradeadbility |
% |
≥25 |
||
|
Inflation
pressure of tires |
kPa |
260 |
||
|
Working system
pressure |
MPa |
20 |
||
|
Transmission
pressure |
MPa |
1.3-1.8 |
||
|
Working
parameters |
Maximum steering
angle of front wheels |
° |
±48 |
|
|
Maximum
inclination angle of front wheels |
° |
±17 |
||
|
Maximum swing
angle of front axle |
° |
±15 |
||
|
Maximum swing
angle of balance box |
° |
front 15, rear
15 |
||
|
Maximum steering
angle of frame |
° |
±27 |
||
|
Maximum turning
radius |
m |
7.3 |
||
|
Blade |
Maximum lifting
height |
mm |
400 |
|
|
Maximum
shoveling depth |
mm |
500 |
||
|
Maximum lateral
inclination angle |
° |
90 |
||
|
Cutting angle |
° |
28-70 |
||
|
Oil filling
amount |
Slewing angle |
° |
360 |
|
|
Length x chord
height |
mm |
3965 x 610 |
||
|
Coolant |
L |
50 |
||
|
Fuel tank |
L |
280 |
||
|
Engine |
L |
24 |
||
|
Transmission |
L |
38 |
||
|
Balance box |
L |
46 |
||
|
Drive axle |
L |
28 |
||
|
Hydraulic oil |
L |
110 |
||
