XCMG Brand GR2405 Chinese New Tractor Motor Grader 250HP with Attachment

Chat Now 1 / EA (Min. Order)
Model: GR2405
Engine: Cummins
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Brand GR2405 Chinese New Tractor Motor Grader 250HP with Attachment

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

Specifications

  • Weight:16700.000kg
  • Condition:New
  • Moving Type:Other

XCMG Brand GR2405 Chinese New Tractor Motor Grader 250HP with Attachment

XCMG Brand GR2405 Chinese New Tractor Motor Grader 250HP with Attachment



The motor grader is mainly used for ground leveling, ditching, slope scraping, bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc. It is the necessary construction machinery for national defense construction, mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.



1. Utilizing load sensitive hydraulic system, small control force, good control feeling, realizing micro control.

2. Engine variable power control technology, more energy efficient.

3. Intelligent fan control technology enables fan speed changing with the real-time detected system temperature, low energy consumption and low noise.


4. Wet type brake axle, long lifetime, higher reliability.

5. Elevated cabin allows bigger operation space.

6. Optimal arrangement of the air conditioning flue, integration with cab interior design, better air conditioning effect.

7. Advance antivibration and noise reduction technology, low noise of the whole machine.

8. The working device is more reliable with the integral angle position device, high strength rotary support and overload protection worm gearbox.

XCMG Brand GR2405 Chinese New Tractor Motor Grader 250HP with Attachment

Item

GR2405

Basic parameters

Engine model

QSB6.7

Rated power/speed

178kW/2200rpm

Overall dimension (standard)

9300x2625x3420

Total weight (standard)

17000 kg

Tire specification

17.5-25

Ground clearance (front axle)

586mm

Space of front and rear axles

6447 mm

Space of middle and rear wheels

1538 mm

Performance
parameters

Forward velocity

5,8,11,19,23,38km/h

Reverse speed

5,11,23km/h

Tractive effort f=0.75

88kN

Maximum gradeability

25%

Tire inflation pressure

260kPa

Working system pressure

22MPa

Transmission pressure

1.85-2.2Mpa

Working parameters

Maximum steering angle of front wheel

±48°

Maximum slant angle of front wheel

±17°

Maximum oscillating angle of front axle

±15°

Maximum oscillating angle of equilibrium box

forwards15°, Reverse15°

Maximum steering angle of frame

±25°

Minimum turning radius

7.3m

Scrape knife

Maximum lift height

480mm

Maximum cutting depth

715mm

Maximum tilt angle

90°

Cutting angle

29°-69°

Angle of revolution

360°

Length & chord height

3965x610mm

Oil filling amount

Coolant

50L

Fuel tank

270L

Engine

24L

Transmission

38L

Equilibrium box

60L

Drive alex

36L

Hydraulic oil

190L
