XCMG Schwing 132kW truck mounted concrete pump HBC9018VD China new concrete pumps truck machine pric

View All >

Model： HBC9018VD

Engine： Wannan

After-sales Service： Engineers available to service machinery overseas

Min Order Quantity： 1 Unit

Delivery Time：

In Stock (Within 7 days)

Production (Within15 to 20 days)

Customization (negociated delivery time)

After-sales Service：

1. It is recommended that you keep in touch with the seller after purchasing offline...

About after-sales service:

1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:

1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.

Inquiry Chat Now

Favorite Products

Product:

XCMG Schwing 132kW truck mounted concrete pump HBC9018VD China new concrete pumps truck machine pric

Quantity:

- + /EA

Content:

Or choose from these questions:

What is the best price you can offer?

Do you support customization?

What is the MOQ for this product?

*Email:

Full Name:

Mobile phone:

HBC9018VD

Specs & Compare

Details

Specs & Compare

Select 3 models for comparison

Dimension(L*W*H)

Weight

Power(W)

Model Number

Brand Name

Place of Origin

Power Type

Certification

Engineering & Construction Machinery

HBC9018VD

9185×2525×2790mm

14000kg

132kW

HBC9018VD

XCMG

Xuzhou, Jiangsu, China

CE/ISO9001

+ Add a Product

Summary

Dimension(L*W*H):9185×2525×2790mm
Weight:14000kg
Power(W):132kW
Model Number:HBC9018VD
Brand Name:XCMG
Place of Origin:Xuzhou, Jiangsu, China
Certification:CE/ISO9001

Specifications

weight:14000.000kg
Condition:New
Moving Type:Wheel
Color:Red
Filling height:1500mm
Hopper volume:0.6m3
PTO way:Upper mounted motor
Hydraulic oil tank volume:650L
Emission standard:China V
Fuel oil tank capacity:280L

Packaging & Shipping

Delivery Lead Time:7 days for ready goods
Minimum Order:1 Piece
Supply Ability:10,000 Set/ Sets per Month
Total Quantity In Stock:Over 5000
Delivery Port:Any Port In China

XCMG Schwing 132kW truck mounted concrete pump HBC9018VD China new concrete pumps truck machine pric

132kW truck mounted concrete pump HBC9018VD China new concrete pumps truck machine.

XCMG HBC9018VD truck-mounted pump has more reliable full hydraulic reversing technology, stable reversing buffer technology-MPS (micro impact) reversing buffer technology. It is a dedicated work vehicle for concrete pumping, and the dedicated device is a central pumping system.

Performance characteristic:

1. More reliable full hydraulic reversing technology.

2. Ultra-high pressure pumping technology.

3. Hydraulic system technology with ultra-low pressure loss.

4. More reliable high and low voltage automatic switching technology.

5. More advanced power matching technology.

6. Safer and smarter electrical control technology.

XCMG Schwing 132kW truck mounted concrete pump HBC9018VD China new concrete pumps truck machine pric

Item	Category		Unit	Technical Parameters
Model	Announcement model			XZS5140THB
Model	Product model			HBC9018VD
Overall parameter	Outline dimension		mm	9185×2525×2790
	Max.total mass		kg	14000
	Filling height		mm	1500
Working parameter	Theoretical displacement	low pressure	m³/h	90
	Theoretical displacement	high pressure	m³/h	45
	Theoretical output	low pressure	MPa	10
	Theoretical output	high pressure	MPa	18
	Delivery cylinder diameter ×stroke		mm	φ230×1600
	Hopper volume		m³	0.6
	Engine/Motor	Rated power	kW	132
		Brand	-	Wannan
		PTO way	-	Upper mounted motor
	Hydraulic oil tank volume		L	650
Chassis parameter	Brand		-	Dongfeng
	Engine power		kW	132
	Emission standard		-	China V
	Fuel oil tank capacity		L	280L
