XCMG schwing concrete mixing plant HZS180V China big 180m3 new concrete batching plant price list
Summary
- Certification:CE/ISO9001
- Power(W):2×55kW
- Model Number:HZS180V
- Brand Name:XCMG
- Place of Origin:Xuzhou,Jiangsu,China
Specifications
- Weight:1.000kg
- Condition:New
- Moving Type:Other
- Theoretical production rate:180m³/h
- Mixer type:JS3000
- Discharge height:4m
- Nominal volume of mixer:3000L
- Production period:60S
- Volume of aggregate silo:4×40m³
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG schwing concrete mixing plant HZS180V China big
180m3 new concrete batching plant.
XCMG HZS180VG mobile concrete batching plant more
efficient production, smarter control, more accurate measurement, more uniform
mixing, more comprehensive customization, more cutting-edge environmental
protection, and higher quality delivery.
1.Cutting-edge Environmental-care
XCMG not only provides conventional environmental
schemes, but commits itself to the application and development of cutting-edge
environmental technologies.
2.More Efficient Production
Realize zero-speed start, high-speed hoist and low-speed
stop, with high speed and small impact. Providing more reliable operation and
better continuous production.
3.More Uniform Agitating
Features faster material cycle, more violent
countercurrent and more uniform agitating. Greatly reducing cleaning intensity
of labor.
4.More Comprehensive Customization
All-around and 3D environmental measures are taken to
effectively control the pollution. Realize all-around control of people,
vehicles, pumps and plants.
|
Model |
Unit |
HZS180V |
|
Theoretical
production rate |
m³/h |
180 |
|
Discharge
height |
m |
4 |
|
Mixer type |
/ |
JS3000 |
|
Mixer power |
kW |
2×55 |
|
Nominal volume
of mixer |
L |
3000 |
|
Production
period |
S |
60 |
|
Max. diameter
of aggregate |
mm |
≤80 |
|
Volume of
aggregate silo |
m³ |
4×40 |
|
Volume of
powder silo (optional) |
t |
4×200 |
|
Capability of
batching plant |
L/Silo |
4800 |
|
Delivery
capacity of inclined belt conveyor |
t/h |
700 |
|
Productivity
of cement spiral conveyer |
t/h |
90 |
|
Productivity of
flyash spiral conveyor |
t/h |
90 |
|
Standard
installed capacity |
kW |
270 |
|
Gravel weighing
range and accuracy |
kg |
(1080～3600)±2% kg |
|
Sand weighing
range and accuracy |
kg |
(810～2700)±2% kg |
|
Weighing range
and accuracy of cement |
kg |
(540～1800)±1% kg |
|
Admixture
weighing range and accuracy |
kg |
(240～800)±1% kg |
|
Weighing range
and accuracy of water |
kg |
(240～800)±1% kg |
|
Weighing range
and accuracy of additive |
kg |
(20～60)±1% kg |
