XCMG Official 11 ton mining loader LW1100KV Chinese large mining wheel loader machine price
Specifications
- Weight:11000.000kg
- Rated Load:11000kg
- Model Number:LW1100KV
- Brand Name:XCMG
- Dimension(Long * Breadth * High):10139x3639x3950mm
- Machine Weight: 35000kg
- Place of Origin:Jiangsu, China
- Bucket capacity:5.5-6.1m3
- Engine Brand:Cummins
- Type: front loader
- Moving Type: wheel loader
- Certification: CE/ISO
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official 11 ton mining loader LW1100KV Chinese large mining wheel
loader machine price.
LW1100KV
is one main model of XCMG V series high-tonnage wheel loader and is leading the
domestic industry development. It's rooted in the customers' needs and based on
the international R&D platform to thoroughly improve the product
reliability, economy, energy-saving, environmental-friendliness, comfort, and
maintenance convenience.
With
heavy-duty design and high firmness and reliability and globally supplied
critical parts, this product is extensively applied in the productions of mine,
logistics, cement, and steel enterprises.
Performance
Characteristics:
* High
efficiency drive system
The
world's leading full-automatic electronic control transmission is equipped,
with four-forward and three-reverse gears, automatic/manual mode switchover
function, and KD function.
* High
efficiency hydraulic system
The
load-sensing variable technology is adopted to supply pressure and flow
depending on the working needs, which reduces the fuel consumption by 15%.
*
High-efficiency working device
The high-
efficiency linkage system is fitted with limit sensing mechanism with angle
memory function, featuring higher limiting accuracy and working efficiency.
* Engine
The
three-stage air filter is designed especially for severe working environment of
construction machinery industry.
The
multi-stage fuel filter ensures good fuel adaptability and guarantees
cleanliness of engine system.
|
Description |
Specification |
Unit |
|
|
Rated operating load |
11000 |
kg |
|
|
Bucket capacity |
5.5-6.1 |
m³ |
|
|
Machine weight |
34000-35000 |
kg |
|
|
Dump clearance at maximum lift |
3450 |
mm |
|
|
Reach at maximum lift |
1494 |
mm |
|
|
Wheel base |
3700 |
mm |
|
|
Tread |
2450 |
mm |
|
|
Max. breakout force |
290 |
kN |
|
|
Hydraulic cycle time-raise |
6.6 |
s |
|
|
Total hydraulic cycle time |
11.9 |
s |
|
|
Min. turning radius over tyres |
6306 |
mm |
|
|
Articulation angle |
40 |
° |
|
|
Gradeability |
25 |
° |
|
|
Tyre size |
29.5R25 |
||
|
Overall machine dimension L×W×H |
10139*3639*3950 |
mm |
|
|
Model |
QSX15 |
||
|
Rated Power/Speed |
291/2000 |
kw/rpm |
|
|
Travel speed |
1-gear(F/R) |
6.2/6.2 |
km/h |
|
2-gear(F/R) |
11.5/11.5 |
km/h |
|
|
3-gear(F/R) |
17.5/24.8 |
km/h |
|
|
4-gear(F/R) |
35.7/- |
km/h |
|
