XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

  • XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
  • XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
  • XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
  • XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
  • XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
  • XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
  • XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

Share:
XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
FOB for Loader Reference Price:Get Latest Price
$10000.00-$1000000.00 1 / EA (Min. Order)
Model: LW1400KN
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
Summary
  • Rated Load:14 Ton
  • Dimension(Long* Breadth * High):12337x3980x4319mm
  • Type:Mining Loader
  • Place of Origin:Jiangsu,China
  • Model Number:LW1400KN
  • Brand Name:XCMG
  • Certification:CE/ISO9001
Details
  • weight:14000.000kg

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader.



LW1400KN mining loader is the China's largest tonnage loader independently developed by XCMG, featuring firm structure, strong power, high stability and reliability, high safety and com­fort, and energy-saving and high efficiency.



1.The LW1400KN loader is mainly used in harsh working conditions such as mines, with excellent transmission system, strong power and good passability of the whole machine.



2.The structural parts have passed 30,000 hours of market fatigue verification and have high reliability.



3.The newly optimized hydraulic system and linkage mechanism, the machine has strong working capacity and high working efficiency.



4.Its new integrated FOPS&ROPS ultra-quiet cab not only provides driver with wide vision, but more importantly safety and comfort.



5.The gearbox and drive axle of interna­tional leading quality joined by XCMG's exclusive power matching technology makes the machine more efficient and reliable.



6.The load-sensitive variable & constant power control technology is applied to provide pressure and flow according to operation needs, greatly reducing fuel consumption.



XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

Description

Specification

Unit

Rated operating load

14000

kg

Bucket capacity

7.0

m3

Machine weight

53000

kg

Max.breakout force

394

kN

Total hydraulic cycle time

14.0

s

Min.turning radius overtyres

7622

mm

Articulation angle

40

o

Gradeability

25

o

Tyre size

35/65R33



Model

CummnisQSK19



Rated Power/speed

418/2000

kW/rpm

I-gear(F/R)

6.5/6.5

km/h

n-gear(F/R)

12/12

km/h

Travel speed m-gear(F/R)

20/20

km/h

IV-gear(F)

33/33

km/h

tread

4500

mm

Wheel tread

2710

mm

Dump clearance at maximum lift

3845

mm

Reach at maximum lift

2168

mm

Minmum ground clearance

505

mm

Overall machine dimension LxWxH

12337x3980x4319

mm

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates





uMore Mining Loader





XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

XCMG LW1400KN 14 Ton Heavy Duty Mining Loader With CE / ISO Certificates

Send your message to this supplier
Email:
to:
XCMG E-commerce Inc.
Content:
/6000

Your inquiry content must be between 20 to 6000 characters.

Quantity:
/ Set
back to top
Response Time : Within 24 hours
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
