XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale

  • XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale
  • XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale
  • XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale

Share:
XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale
FOB for Road Mach Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Shipping
Payment Terms:
XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale
  • Summary
  • Details
Summary
  • Brand Name:XCMG
  • Place of Origin:China
Details
  • Product Name:G5C185273D6BB7
  • Display online time:2019-11-18
  • weight:3500.000kg
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Warranty:3 Months
  • Condition:NEW
  • Moving Type:other

XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale


XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale

1.5-3.5T 4 wheel electric forklift:

• Full AC System

• OPS System

• Comfortable Operator Space

• Side-way Battery Change System

• Lower Energy Consumption and Energy Regeneration Function

• Easy-to-read operator display

• Front Dual AC Motor Traction System

• World Class Gear Box System

• Automatic Maintenance Alarm

• Zero-Emission,Zero-Pollution,Low-Level Vibration,Low-Level Vibration,Low Operation Cost, High Efficiency ,High Quality,these are the reasons for you to choose a XCMG Electric Forklift.

• The most advanced 3-phase full AC technology in XCMG’s electric range combining the Italian ZAPI electric controller,ZAPI-SUPEREC AC motors,and HAKWER battery,as well as the excellent hydraulic system,these features guarantee your material handling become the most cost-efficient.

• The Energy Regeneration Function extend extra 15% working hours,which provide the possibility for your tough and long-time working condition.

XCMG Official 1.5-3.5T 4 Wheel Electric Forklift for sale

1.5T 4 wheel electric forklift
ModelFB15-AZ1
Rated Load CapacityQ(kg)1500
Load CentreC(mm)500
Lift HeightH3(mm)3000
Free LiftH2(mm)100
Fork Size (L×W×T)L/W/T(mm)920×120×35
F/B(α°/β°)Deg6°/12°
Length (To Fork Face)L1(mm)2150
WidthB1(mm)1090
Mast Lowered HeightH1(mm)2025
Mast Extended Height
(With Backrest)
H4(mm)4055
Overhead Guard HeightH5(mm)2125
Turning RadiusWa(mm)1995
Fork Overhang
 (Wheel Center to Fork Face)
X(mm)409
Front TreadB2(mm)890
Rear TreadB3(mm)920
Ground ClearanceH6(mm)110
WheelbaseY(mm)1380
Fork Spread (Min/Max)mm240/970
Travel Speed (Full Load)km/h12
Travel Speed (No Load)km/h13
Lifting Speed (Full Load)mm/s280
Lifting Speed (No Load)mm/s380
Total Weight
(Include Battery Box)
kg3060
Tyre (Front x 2)6.50-10-10PR
Tyre (Rear x 2)5.00-8-8PR
Diver Motorkw7.5
Pump Motorkw9.2
Battery (Standard)V/Ah48/450
Controller  Type AC
Controller ManufacturerZAPI
Operating PressureMpa14.5
2 -2.5T 4 wheel electric forklifts
ModelFB20-AZ1FB25-AZ1
Rated Load CapacityQ(kg)20002500
Load CentreC(mm)500
Lift HeightH3(mm)3000
Free LiftH2(mm)100100
Fork Size (L×W×T)L/W/T(mm)1070×120×401070×120×40
F/B(α°/β°)Deg6°/12°
Length (To Fork Face)L1(mm)23802380
WidthB1(mm)11501150
Mast Lowered HeightH1(mm)20552055
Mast Extended Height
 (With Backrest)
H4(mm)40704070
Overhead Guard HeightH5(mm)21252125
Turning RadiusWa(mm)20802080
Fork Overhang
 (Wheel Center to Fork Face)
X(mm)478478
Front TreadB2(mm)970970
Rear TreadB3(mm)950950
Ground ClearanceH6(mm)120120
WheelbaseY(mm)15001500
Fork Spread (Min/Max)(mm)250/1040250/1040
Travel Speed (Full Load)km/h12
Travel Speed (No Load)km/h13
Lifting Speed (Full Load)mm/s300300
Lifting Speed (No Load)mm/s420420
Max.Gradeability
 (Full Load)
%18
Max.Gradeability
 (No Load)
%20
Total Weight
 (Include Battery Box)
kg41604660
Tyre (Front x 2)7.00-12-12PR7.00-12-12PR
Tyre (Rear x 2)18×7-8-14PR18×7-8-14PR
Diver Motorkw1111
Pump Motorkw1111
Battery (Standard)V/Ah48/62048/620
Controller  Type AC
Controller ManufacturerZAPI
3 -3.5T 4 wheel electric forklifts
ModelFB30-AZ1FB35-AZ1
Rated Load CapacityQ(kg)30003500
Load CentreC(mm)500
Lift HeightH3(mm)3000
Free LiftH2(mm)100100
Fork Size (L×W×T)L/W/T(mm)1070×125×451070×125×50
F/B(α°/β°)Deg6°/12°
Length (To Fork Face)L1(mm)24752535
WidthB1(mm)12251225
Mast Lowered HeightH1(mm)20702070
Mast Extended Height
 (With Backrest)
H4(mm)40704070
Overhead Guard HeightH5(mm)21252125
Turning RadiusWa(mm)22152280
Fork Overhang
(Wheel Center to Fork Face)
X(mm)485485
Front TreadB2(mm)10001000
Rear TreadB3(mm)980980
Ground ClearanceH6(mm)130130
WheelbaseY(mm)16001600
Fork Spread (Min/Max)mm250/1100250/1100
Working Aisle Width With Pallet
 (1000×1200,1200 Lengthways)
mm39704035
Working Aisle Width With Pallet
(800×1200,800 Lengthways)
mm41004165
Travel Speed (Full Load)km/h12
Travel Speed (No Load)km/h13
Lifting Speed (Full Load)mm/s280280
Lifting Speed (No Load)mm/s440440
Max.Gradeability (Full Load)%1612
Max.Gradeability (No Load)%1813
Total Weight
 (Include Battery Box)
kg51605660
Tyre (Front x 2)28×9-15-12PR28×9-15-12PR
Tyre (Rear x 2)18×7-8-14PR18×7-8-14PR
Diver Motorkw1212
Pump Motorkw1212
Battery (Standard)V/Ah80/50080/500
Controller  Type AC
Controller ManufacturerZAPI
Operating PressureMpa17.517.5
