Summary
- Weight:≤7800/7300
- Power(W):92kW
- Model Number:XM503
- Brand Name:XCMG
- Place of Origin:China
- Milling width (mm):500
- Milling depth (mm):120
Details
- Product Name:G5E5E27BD5679E
- Display online time:2020-05-06
- weight:7800.000kg
- After-sales Service Provided:Engineers available to service machinery overseas
- Warranty:12 Months
- Condition:NEW
- Moving Type:other
|
Item |
Unit |
XM503 |
|
Milling width |
mm |
500 |
|
Maximum milling depth |
mm |
180 |
|
Cutter tip pitch |
mm |
15 |
|
Amount of tools(piece) |
(piece) |
54 |
|
Diameter of rotor |
660 |
|
|
Engine model |
SC4H-C140 |
|
|
Engine manufacturer |
Shangchai |
|
|
Rated speed |
rpm |
2200 |
|
Rated power |
Kw |
92 |
|
Emission standard |
China-III |
|
|
Fuel tank |
L |
140 |
|
Water tank |
L |
300 |
|
Working speed |
m/min |
0-40 |
|
Traveling speed |
Km/h |
0-6 |
|
Theoretical gradeability |
% |
50 |
|
Maximum unloading height |
mm |
1200 |
|
Theoretical unloading capacity |
m3/h |
42 |
|
Gross machine weight |
Kg |
≤7800/7300 |
|
Minimum milling radius |
mm |
350 |
|
Ground clearance |
mm |
180 |
