XCMG QY50KA truck crane 50 ton 58m with catalog PDF for sale
FOB for Cranes Reference Price:Get Latest Price
$140000.00-$160000.00 1 / EA (Min. Order)
Model: QY50KA
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG QY50KA truck crane 50 ton 58m with catalog PDF for sale
XCMG QY50KA truck crane 50 ton 58m with catalog PDF for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
  • 360-Degree VR Videos
  • Product PDF
Summary
  • Model Number:QY50KA
  • Brand Name:XCMG
  • Place of Origin:XUZHOU, CHINA
  • Max. Lifting Height:58.1m
  • Max. Lifting Load:50 ton
Specifications
  • weight:1.000kg
  • Condition:New
  • Moving Type:Wheel
  • Feature:truck crane
  • Wheel base:2304+2075mm

XCMG QY50KA truck crane 50 ton 58m with catalog PDF for sale

XCMG QY50KA truck crane 50 ton 58m with catalog PDF.



1. XCMG 50 ton  truck crane QY50KA Leading lifting and driving performances.

Five section U-type booms. The boom length is 11.4m-43.5m with strong lifting performance, leading 5%-10% ahead of products with the same tonnages in the same industry.



2. High-power engine with good dynamic performance, strong gradeability and superior trafficability. The maximum gradeability and maximum travel speed respectively are 42% and 85km/h.



3. Reliability of heat dissipation, electrical system etc. has been improved with safer operation and driving

Waterproof connector clip is equipped with rubber sheath inside with excellent water impervious and level of protection reaches to IP65.



4. The air-conditioning condenser is separately installed, the heat-sinking capability is sharply improved and the environment temperature reached to more than 45℃.



5. Air-aid shift gears and 45% of shifting force is reduced

The boost system will work only by stepping on the clutch that effectively avoids gearbox damaging gears when shifting. Compared with the same industry, 100mm distance of shift gears and 45% of shifting force are respectively reduced.



XCMG QY50KA truck crane 50 ton 58m with catalog PDF for sale

Description

Unit

Parameter value

Overall length

mm

13930

Overall width

mm

2780

Overall Height

mm

3630

Axle base

1st ,2nd axle

mm

1470



2nd ,3rd axle



4300



3rd ,4th axle



1350

Wheel Base

mm

2304+2075

Front overhang/rear overhang

mm

2389/2064or 2376/2064

Front extension/rear extension

mm

2131/226 or 2144/226

Total vehicle mass in travel configuration

kg

42200

Axle load

Front axle

kg

16200



Rear axle



26000

Engine Model



WD615.338

Engine rated power

kw/(r/min)

276/2200

Engine rated torque

N.m/(r/min)

1500/1300-1600

Max. travel speed

km/h

85

Min. steady travel speed

km/h

2~3

Min. turning diameter

m

24

Min. ground clearance

mm

327

Max. grade ability

%

42

Approach angle

°

19

Departure angle

°

15

Braking distance (at 30 km/h, full load )

m

≤10

Oil consumption per 100km

L

40

Exterior noise level during acceleration traveling

dB (A)

≤88

Noise level at seated position

dB (A)

≤90
