XCMG Official small bulldozers TY160 China new 160hp crawler bulldozer machine for sale

$10000.00-$1000000.00 1 / EA (Min. Order)
Model: TY160
Engine: WEICHAI
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Official small bulldozers TY160  China new 160hp crawler bulldozer machine for sale

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Dimension(Long * Breadth * High):5128*3416*3120mm
  • Machine Weight:18200kg
  • Model Number:TY160
  • Brand Name:XCMG
  • Place of Origin:Jiangsu, China
  • Certification:CE/ISO

Specifications

  • Weight:18200.000kg
  • Condition:New
  • Moving Type:Other
  • Moving Type:Crawler Bulldozer
  • Minimum turning radius:3100mm
  • Maximum traction power:148kN
  • Warranty of core components:1 Year

XCMG Official small bulldozers TY160  China new 160hp crawler bulldozer machine for sale

XCMG Official small bulldozers TY160 China new 160hp crawler bulldozer machine.



The TY160 crawler bulldozer which has excellent power, reliability and a long service life. Through the introduction of Japanese D65A-8 bulldozer technology, at the same time absorb the advantages of D60A-8, The TY160 crawler type bulldozer has been developed by the domestic design.


Technical Characteristics:



* The appearance of the vehicle is based on optimization design.



* High engine power reserve, strong torque output, low fuel consumption, reliable controls.



* Hydraulically powered, automatic speed change, shift the gears without stop the vehicle.



 * 3 elements, single stage and single phase torque convertor features high efficiency and capacity.



* The updated hexahedral cab features outstanding visibility and good tightness.



* Using the triangle spline and the gear of crowned teeth and tip relief in the final drive to average the loads on the trans-mission components for more stability, prolong the lifetime.



* New blade is more durable and capacious.



* Alarming & monitoring system is reliable.



* Reliable manual- operated spool valve and external mounted valve for easy maintenance.

XCMG Official small bulldozers TY160  China new 160hp crawler bulldozer machine for sale

Name

Remarks

Specifications

Overall size of the machinemm

Straight shovel, traction rod

5128×3416×3120

Straight shovel, three toothed soil loosen

6215×3416×3120

The use quality of the whole machinekg

Straight shovel, traction rod

17100

Straight shovel, three toothed soil loosen

18700

Maximum traction power (kN)

148

Minimum turning radius (mm)

3100

Maximum climbing performance (°)

30

Minimum ground clearance (mm)

No crawler

400

Average ground specific pressure (MPa)

0.065

Forward speed (km/h)

F1

3.1

F2

5.47

F3

9.07

Back speed (km/h)

R1

4.03

R2

7.12

R3

11.81

Tracked ground length (mm)

2430

Caterpillar center distance (mm)

1880

Production efficiency (m3/h)

30m distance

350

Engine

Model

Weichai WD10G178E25

type

Water cooling,straight line,four stroke,direct injection

The number of cylinder - bore * stroke (mm)

6126×130

Rated power (kW)

131

Rated speed (r/min)

1850

Maximum torque (N.m/r/min)

830/10001200

Fuel consumption rate (g/kW.h)

≤210

Walking system

type

Swing type and balance beam suspension structure

Pitch (mm)

203.2

Number of wheels of single side belt

2

Number of single side pulley

unilateral and 2 bilateral

6

Crawler height (mm)

60

Working device

Straight shovel single shovel capacity (M3)

3.9

The maximum lifting height of the blade (mm)

1095

The maximum depth of soil cutting blade (mm)

545

The maximum tilt blade height (mm)

860

Type of soil looser

Three teeth

Three tooth looser tooth distance (mm)

950

Three tooth looser

Soil depth (mm)

572

Elevation (mm)

702

The three tooth scarifier weight (kg)

1621
