XCMG official 160HP Bulldozer TY160 China new mini small crawler dozer bulldozer with parts price
Summary
- Dimension(Long * Breadth * High):5128*3416*3120mm
- Machine Weight:18200kg
- Model Number:TY160
- Brand Name:XCMG
- Place of Origin:Jiangsu, China
- Certification:CE/ISO9001
Specifications
- weight:18200.000kg
- Condition:New
- Moving Type:Other
- Maximum traction power:148kN
- Minimum turning radius:3100mm
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
160HP Bulldozer TY160 China new mini small crawler dozer
bulldozer with parts.
The XCMG TY160 crawler bulldozer which has excellent
power, reliability and a long service life. Through the introduction of
Japanese D65A-8 bulldozer technology, at the same time absorb the advantages of
D60A-8, The TY160 crawler type bulldozer has been developed by the domestic
design.
Technical Characteristics:
1.High engine power reserve, strong torque output, low
fuel consumption, reliable controls.
2.Hydraulically powered, automatic speed change, shift
the gears without stop the vehicle.
3.3 elements with features high efficiency and capacity.
4.The cab features outstanding visibility and good
tightness.
5.Promote more stability, prolong the lifetime.
6.Alarming & monitoring system is reliable.
Name | Remarks | Specifications |
Overall size of the machine（mm） | Straight shovel, traction rod | 5128×3416×3120 |
Straight shovel, three toothed soil loosen | 6215×3416×3120 | |
The use quality of the whole machine（kg） | Straight shovel, traction rod | 17100 |
Straight shovel, three toothed soil loosen | 18700 | |
Maximum traction power (kN) | 148 | |
Minimum turning radius (mm) | 3100 | |
Maximum climbing performance (°) | 30 | |
Minimum ground clearance (mm) | No crawler | 400 |
Average ground specific pressure (MPa) | 0.065 | |
Forward speed (km/h) | F1 | 3.1 |
F2 | 5.47 | |
F3 | 9.07 | |
Back speed (km/h) | R1 | 4.03 |
R2 | 7.12 | |
R3 | 11.81 | |
Tracked ground length (mm) | 2430 | |
Caterpillar center distance (mm) | 1880 | |
Production efficiency (m3/h) | 30m distance | 350 |
Engine | ||
Model | Weichai WD10G178E25 | |
type | Water cooling, straight line, four stroke, direct injection | |
The number of cylinder - bore * stroke (mm) | 6－126×130 | |
Rated power (kW) | 131 | |
Rated speed (r/min) | 1850 | |
Maximum torque (N.m/r/min) | 830/1000～1200 | |
Fuel consumption rate (g/kW.h) | ≤210 | |
Walking system | ||
type | Swing type and balance beam suspension structure | |
Pitch (mm) | 203.2 | |
Number of wheels of single side belt | 2 | |
Number of single side pulley | unilateral and 2 bilateral | 6 |
Crawler height (mm) | 60 | |
Working device | ||
Straight shovel single shovel capacity (M3) | 3.9 | |
The maximum lifting height of the blade (mm) | 1095 | |
The maximum depth of soil cutting blade (mm) | 545 | |
The maximum tilt blade height (mm) | 860 | |
Type of soil looser | Three teeth | |
Three tooth looser tooth distance (mm) | 950 | |
Three tooth looser | Soil depth (mm) | 572 |
Elevation (mm) | 702 | |
The three tooth scarifier weight (kg) | 1621 | |
