XCMG Official 16 ton truck crane China cranes XCT16 Truck Crane price
FOB for Cranes Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Official  16 ton truck crane China cranes XCT16 Truck Crane price
XCMG Official  16 ton truck crane China cranes XCT16 Truck Crane price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Model Number:XCT16
  • Brand Name:XCMG
  • Place of Origin:China
  • Span:7.9m
  • Max. Lifting Height:40.5 m
  • Max. Lifting Load:16t
  • Application:Construction Industry
  • Certification:ISO9001
Specifications
  • weight:23300.000kg
  • Condition:New
  • Moving Type:Wheel
  • Overall length:11960mm
  • Overall width:2500mm
  • Overall height:3330mm
  • Total weight in travel:23300kg
  • Engine Model:SC7H245Q5
  • Engine rated power:180kW/2300rpm
  • Engine rated torque:960Nm/1200~1600rpm
  • Driving speed(km/h):2~85
  • Gradability:0.48
  • Min. turning diameter:20m
  • Min. ground clearance:261mm
  • Tires:11.00-20,suitable for heave load truck
  • Base boom:10m
  • Max. main boom:32m

XCMG Official  16 ton truck crane China cranes XCT16 Truck Crane price

XCMG 16 Ton Truck Crane XCT16.


Main parameters:

Max. rated total lifting capacity:16T

Basic boom: 10.5M

Max. main boom:32.5M

Max. main boom+jib:40.6M


Main configuration:

*SHANGCHAI OR WEICHAI engine, SC7H260Q4/SC7H245Q4/WP6. 245.E40(192/180/180kw)

Wire rope

Hirschmann PAT

*Heater

*Full dimension cab

XCMG XCT16 has four 12-section cross-section of the new main boom, the main arm length of 32m, jib length of 8.15m, are leading the industry's highest level; lifting machine industry, the highest standard with the fifth leg, to achieve 360 ° operation.


OUR SERVICE:

* Warranty: We supply one-year warranty for all the machines we exported, during the warranty, if there is problem caused by machine quality without improper operation, we will supply the replace genuine parts by DHL to clients freely to keep the machine in high efficiency work.


* Spare Parts: We have 7years experience on machine and spare parts supplying, we are efforts to supply Genuine brand spare parts with good prices, quick response and professional service.

XCMG Official  16 ton truck crane China cranes XCT16 Truck Crane price

Dimension

Unit

XCT16

Overall length

mm

11960

Overall width

mm

2500

Overall height

mm

3330

Weight

Total weight in travel

kg

23300

Power

Engine model

SC7H260Q4/SC7H245Q4/WP6.245.E40

Engine rated power

kW/(r/min)

192/2300  180/2300 180/2300

Engine rated torque

N.m/(r/min)

1000/1200~1600 960/1200~1600 900/1100~1700

Travel

Max. travel speed

km/h

85

Min. turning diameter

m

20

Min. ground clearance

mm

261

Approach angle

°

19/12

Departure angle

°

14

Max. grade ability

%

48

Fuel consumption for 100km

L

28

Main performance

Max. rated total lifting capacity

t

16

Min. rated working radius

m

3

Turning radius at turntable tail

m

3.18

Max. lifting torque

kN.m

730

Base boom

m

10.5

Max.main boom

m

32.5

Max.main boom+jib

m

40.6
