XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

  • XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale
  • XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale
  • XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale
  • XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale
  • XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale
  • XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

Share:
XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale
FOB for Cranes Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: XCT80L6
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale
XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Model Number:XCT80L6
  • Brand Name:XCMG
  • Place of Origin:Jiangsu,China
  • Max. Lifting Height:74.5m
  • Rated Loading Capacity:80t
  • Application:Construction
  • Certification:CE/ISO9001
Specifications
  • weight:80000.000kg
  • Condition:New
  • Moving Type:Other

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane.



XCT80L6 Truck crane is widely used for the lifting operations in general engineering projects, such as construction site, urban renewal, communication and transportation, ports, bridge, oilfields and mine, and complex working environments.



1. Super lifting performance



6-section boom of 50m with U-type profile is the longest of the same class in the industry; the max. The performance is 20~30% higher than that of the competitors. The telescoping mode is updated from sequential telescoping to random telescoping. New single-cylinder pinning telescoping system brings higher telescoping reliability.

2. New energy-saving hydraulic system

* The min. stable slewing speed is 0.1°/s. The min. stable lifting speed (drum) is 2.5m/min. Precise and safe lifting movements can be realized.

* Independent cooling technology of the hydraulic motor can make the thermal balance temperature of the hydraulic system below 80. It can work normally in the high temperature environment and thus the hoisting operation is safe and reliable.

3. Drive train

Heavy truck group MAN engine, rated power 268kw, max torque 1800N.m Shangchai diesel engine, rated power 251kw, max torque 1600N.m

4. Low-speed large-torque power drive system

Resulting in perfect combination of high-power performance and low fuel consumption, i.e.12% reduction in fuel consumption for driving, 15% for operation, and 15% improvement in power performance.

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

Weight

Axle

1

2

3

4

Total weight

t

12

12

12

12

48

The 1.5 ton Counterweight should be put on the chassis deck,not taking any other counterweight and rearview mirror;

The main block should be fastened in front of the chassis cab,and not taking any other blocks.

Hook

No.of lines

Weight kg

Dimensions mm

Remarks

80t

12

700

1735×554×520

Single hook, Standard

55t

8

470

1600×520×370

Single hook, Optional

7t

1

210

717×370×370

Single hook, Standard

Working speeds

385/95 R 25(14.00 R 25)

45%

Drive

Working speed

Max.single line pull

Rope diameter/length

0-145 m/min, no load, 4th layer

65.7kN

20 mm/240 m

0-90 m/min, no load, 4th layer

63.7kN

20 mm/180 m

0-2.0 r/min

Approx. 55s for boom elevation from -0.5° to 81°

Approx. 430s for boom extension from 11.85m to 55m

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale


XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale



uMore truck crane



XCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for SaleXCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for SaleXCMG Official XCT80L6 80 Ton Mobile Lifting Truck Crane for Sale

Send your message to this supplier
Email:
to:
XCMG E-commerce Inc.
Content:
/6000

Your inquiry content must be between 20 to 6000 characters.

Quantity:
/ Set
back to top
Response Time : Within 24 hours
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
