XCMG China Brand Mining Mine Dump Truck XDE130 Dump Trucks 130ton Good Performance Dumper Trucks

Chat Now 1 / EA (Min. Order)
Model: XDE130
Engine: MTU
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG China Brand Mining Mine Dump Truck XDE130 Dump Trucks 130ton Good Performance Dumper Trucks

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Dimension(L*W*H):11615*6800*5660MM
  • Weight:82000KG
  • Power(W):970000W
  • Max. Speed:50
  • Brand Name:XCMG
  • Certification:ISO/CE
  • Place of Origin:JiangSu,China

Specifications

  • Weight:82000.000kg
  • Condition:New
  • Moving Type:Wheel

XCMG China Brand Mining Mine Dump Truck XDE130 Dump Trucks 130ton Good Performance Dumper Trucks

XCMG China Brand Mining Mine Dump Truck XDE130 Dump Trucks 130ton Good Performance Dumper Trucks.



XCMG boasts a full series of electrically driven dump trucks ranging from 120 t to 360t, which are mostly applied in construction of opencast mining and large-scale earthwork transporting, making XCMG meet diverse mining and construction demands.

Characterized by exceedingly high transport efficiency, comfty operability, low maintenance cost, and long service life, etc., products of this series are of large bearing capacity, firm structure, shockproof performance, and impact resistance, so they are the optimal choice for you in purchase of opencast mining and construction equipments.



Performance Characteristics:

1. High performance engine

Environment-friendly, electronically controlled, powerful diesel engine with less fuel consumption. High torque at low rpm for more traction power ensures strong vehicle climbing ability.

2. AC-DC-AC electric drive system

XCMG trucks utilize AC-DC-AC electric drive system, safe and reliablewith fewer failure rate and maintenance costs. Constant-power and stepless speed regulation are achieved, with more traction power to maximize the productivity.

3. Structurally enhanced frame

* Welded box sectional steel structure.

* High strength alloy steel ensures the frame have high toughness to resist low-pressure impact, good fatigue properties and good weldability.

* Steel castings have been incorporated at key frame pivot points and key load bearing critical portions of the frame, includes the rear body pivot, pump pivot and cross beams, etc.

* The computer-aid design and finite element analysis ensure the frame have enough intensity.

XCMG China Brand Mining Mine Dump Truck XDE130 Dump Trucks 130ton Good Performance Dumper Trucks

Item

Unit

XDE130

Performance parameters

Rated Payload

t

130

Empty Weight

kg

82000

Gross Vehicle Weight

kg

202000

Drive Style

4x2

Max. Speed

km/h

50

Max. Gradeability

%

20

Min. Turning Diameter

m

22

Overall dimension

mm

11615*6800*5660

Engine

Model

16V2000

Rated Power/Speed

kW/rpm

970/2100

Max. Torque/Speed

Nm/rpm

5286/1500

Electric drive

Alternator

A920P

Traction Motor

M360

Ratio

33.67:1

Tires

Standard Tire

33.00R51
