XCMG Official XE470D Crawler Excavator for sale

  • XCMG Official XE470D Crawler Excavator for sale

Share:
XCMG Official XE470D Crawler Excavator for sale
FOB for Excavator Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Shipping
Payment Terms:
XCMG Official XE470D Crawler Excavator for sale
  • Summary
  • Details
Summary
  • Dimension(L*W*H):12090×3582×3860mm
  • Weight:46900kg
  • Model Number:XE470D
  • Brand Name:XCMG
  • Place of Origin:China
  • Power Type:Diesel
  • Type:Crawler Excavator
  • Certification:CE/ISO9001
Details
  • Product Name:XE470D
  • Display online time:2019-11-07
  • weight:46900.000kg
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Warranty:12 Months
  • Condition:NEW
  • Moving Type:crawler
  • Operating weight:46900Kg
  • Bucket capacity:2.2~2.5m³
  • Rotating speed:9.0r/min
  • Ground pressure:83kPa
  • Bucket digging force:287kN
  • Max. digging height:10812mm
  • Max. dumping height:7533mm
  • Max. digging depth:7881mm
  • Max. digging reach:12066mm
  • Min. swing radius:4802mm


XCMG Official XE470D Crawler Excavator for sale


XCMG Official XE470D Crawler Excavator for sale

XE470D Crawler Excavator
1The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.
2The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.
3The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.
4The advanced structure and hinge points on the digging end and the industrys largest rotating angle of the bucket ensure strong soil holding capacity.
XCMG Official XE470D Crawler Excavator for sale

XCMG Official XE470D Crawler Excavator for sale

XCMG Official XE470D Crawler Excavator for sale

Description

Unit

Parameter value

Operating weight

kg

46900

Bucket capacity

m³

2.2-2.5

Engine

Model

Engine

QSM11-C335

Style

Direct injection

---

Four strokes

---

Water cooling

---

Turbo-charging

---

Air to air intercooler

---

No. of cylinders

---

6

Output power

kW/ r/min

274/1800

torque/speed

N.m

1790/1400

Displacement

L

11


Main performance

Travel speedH/L)

km/h

5.4/3.2

Gradeability

%

70

Rotary speed

r/min

9.0

Ground pressure

kPa

83

Bucket digging force

kN

287

Arm digging force

kN

221

Travel traction force

kN

338

Hydraulic system

Main pump

--

K5V200DTH

Rated flow of main pump

L/min

2×360

Main safety valve pressure

MPa

31.4/34.3

Pressure of pilot system

MPa

3.9

Oil Capacity

Fuel tank capacity

L

725

Hydraulic tank capacity

L

430

Engine oil capacity

L

38


Appearance size

Overall length

mm

12090

Overall width

mm

3582

Overall height

mm

3860

Width of platform

mm

2995

Length of crawler

mm

5353

Overall width of chassis

mm

3582

Width of crawler

mm

600

Wheel base of crawler

mm

4292

Crawler gauge

mm

2750

Clearance under counterweight

mm

1324

Min. ground clearance

mm

519

Min. rear-end swing radius

mm

3800


Working scope

Max. digging height

mm

10812

Max. dumping height

mm

7533

Max. digging depth

mm

7881

Max. digging depth at the range of level 8 feet

mm

7700

Max. vertical wall digging depth

mm

6870

Max. digging reach

mm

12066

Min. swing radius

mm

4802


Worker

Standard

Length of boom

mm

7060

Length of arm

mm

3380

Bucket capacity

m³

2.2 Rock bucket

Optional

Length of arm

m³

2900

Bucket capacity

m³

2.3 Rock bucket

2.5 Reinforced bucket
