XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

  • XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
  • XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
  • XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
  • XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
  • XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
  • XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
  • XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
  • XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

Share:
XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
FOB for Excavator Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: XE700D
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
Specifications
  • weight:69000.000kg
  • Condition:New
  • Moving Type:Crawler
  • Operating Weight:69000kg
  • Bucket capacity:2.4~4.6m3
  • Bucket digging force:363 kn

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D.



1.More energy-conservation and environmental protection

* By adopting the international famous brand engine. It meets TIER 3 emission standard, with advantages of strong power, low noise, low fuel consumption and low emission, and is able to meet demands of various construction conditions.



* It adopts high-pressure fuel injection system, and may realize electric control of the whole course of fuel injection through controlling fuel supply actuator and timing actuator with ECM, so as to exactly control fuel injection amount and fuel injection time, thus reducing fuel consumption and enhancing engine efficiency.



2.More reliable and durable

* XE700D adopts Donaldson STG series heavy grayscale air filter imported with original packaging from the USA, with filtering efficiency reaching 99.99%and adapts to working conditions with much dust and humidity.



* XE700D is set with three-stage fuel filtering system (one stage for coarse filtering and two stages for fine filtering) to effectively filter sundries in fuel, thus making sure the engine can run continuously and reliably with high load for a long time under severe working conditions.

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

Description

Unit

Parameter value

Operating weight

kg

69000

Bucket capacity

2.4-4.6

Hydraulic system

Main pump

--

2

Rated flow of main pump

L/min

2×450

Pressure of prime valve

MPa

31.4/34.3

Pressure of travel system

MPa

34.3

Pressure of swing system

MPa

28.5

Pressure of pilot system

MPa

3.9

Oil Capacity

Fuel tank capacity

L

950

Hydraulic tank capacity

L

500

Engine oil capacity

L

48

Appearance size

Overall length

mm

12130

Overall width

mm

4410

Overall height

mm

4700

Width of platform

mm

4410

Length of crawler

mm

5955

Overall width of chassis

mm

4000

Width of crawler

mm

650

Wheel base of crawler

mm

4685

Crawler gauge

mm

2800/3350

Clearance under counterweight

mm

1565

Min. ground clearance

mm

853

Min. tail swing radius

mm

4090

Working scope

Max. digging height

mm

11300

Max. digging depth

mm

6950

Max. digging depth at the range of level 8 feet

mm

6800

Max. vertical wall digging depth

mm

5550

Max. digging reach

mm

11580

Min. swing radius

mm

4750

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price


XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price
XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D PriceXCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price



uMore xcmg mining excavator

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price


XCMG 70 Ton Large Crawler Mine Excavator Machine XE700D Price

Send your message to this supplier
Email:
to:
XCMG E-commerce Inc.
Content:
/6000

Your inquiry content must be between 20 to 6000 characters.

Quantity:
/ Set
back to top
Response Time : Within 24 hours
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
