XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price

  • XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price
  • XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price
  • XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price
  • XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price
  • XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price
  • XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price

Share:
XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price
FOB for Mining Mach Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: XE900D
Engine: Cummins
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price
XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
Specifications
  • weight:89600.000kg
  • Condition:New
  • Moving Type:Other
  • Rated Speed:4.2km/h
  • Max Digging Radius:5200mm
  • Maximum Digging Depth:7250mm
  • Maximum Digging Height:12060mm
  • Bucket capacity:3.5~6.0m3
  • Operating Weight:89600kg
  • Model Number:XE900D
  • Machine Weight:89600kg
  • Brand Name:XCMG
  • Place of Origin:JiangSu,China

XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price

XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price.



The XE series of large mining hydraulic excavators bring you an extraordinary driving experience with lean manufacturing, professional design and excellent reliability. Moreover, this series of products boast strong excavating power and quick operating speed, making them have matchless operating performance and economic efficiency even in severe mining condition.



1. More energy-conservation and environmental protection

By adopting the engine which complies with national stage III emission standard and features with direct injection, four strokes, water cooling, turbocharging, air to air intercooler and six-cylinder, it can meet mining application requirements. Blending with proven, sturdy and durable parts and delicate manufacturing process, higher reliability and efficiency can be achieved.



2. More efficient return

* By adopting the full electric control engine with low speed and large torque customization which complies with excavating working conditions, the torque reserve can be improved by 11% and the oil consumption can be reduced by 9%.

* With high- efficient and large displacement rotary motor, the rotating torque of the whole machine can be improved by 8.8%.



3. More reliable and durable

* High quality integrated electric system, with higher indicator and electric centralized control, the design is more concise and the system is more reliable.

* Replace the bellows with imported expansion tube, the durability and reliability can be greatly improved. By adopting the large-diameter silencer, the exhaust back pressure and noise will be reduced. With the starting motor with higher dust-proof capability adopted, high reliability and strong mining adaptability can be achieved. Improve the material of intake silicon tube of intercooler and structure of intake to reduce the intake resistance in order to avoid the pipe explosion.

XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price

Description

Unit

Parameter value

Operating weight

kg

89600

Bucket capacity

3.5-6.0

Engine

Model

Engine

QSX15

No. of cylinders

---

6

Output power

kW/ r/min

399/2100

torque/speed

N.m

2539/1400

Displacement

L

15

Main performance

Travel speed(H/L)

km/h

4.2/2.8

Gradeability

%

35

Rotary speed

r/min

6.3

Ground pressure

kPa

120.9

Bucket digging force

kN

480

Arm digging force

kN

370

Travel traction force

kN

656

Hydraulic system

Main pump

--

2

Rated flow of main pump

L/min

2×549

Pressure of prime valve

MPa

31.4/34.3

Pressure of travel system

MPa

34.3

Pressure of swing system

MPa

24.5

Pressure of pilot system

MPa

3.9

Oil Capacity

Fuel tank capacity

L

1230

Hydraulic tank capacity

L

760

Engine oil capacity

L

48

Appearance size

Overall length

mm

13570

Overall width

mm

4545

Overall height

mm

5380

Width of platform

mm

3370

Length of crawler

mm

6350

Overall width of chassis

mm

4150

Width of crawler

mm

650

Track length on ground

mm

5070

Crawler gauge

mm

2960/3500

Clearance under counterweight

mm

1660

Min. ground clearance

mm

850

Min. tail swing radius

mm

4700

Working scope

Max. digging height

mm

12060

Max. dumping height

mm

8070

Max. digging depth

mm

7250

Max. digging depth at the range of level 8 feet

mm

7100

Max. vertical wall digging depth

mm

4200

Max. digging reach

mm

12330

Min. swing radius

mm

5200

XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price

XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine PriceXCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine PriceXCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine PriceXCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine PriceXCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine PriceXCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine PriceXCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price



uMore mining excavator



XCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine PriceXCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine PriceXCMG 90 Ton Mining Excavator Large Hydraulic Crawler Excavator XE900D With Cummins Engine Price

Send your message to this supplier
Email:
to:
XCMG E-commerce Inc.
Content:
/6000

Your inquiry content must be between 20 to 6000 characters.

Quantity:
/ Set
back to top
Response Time : Within 24 hours
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
