XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price

  • XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
  • XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
  • XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
  • XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
  • XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
  • XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price

Share:
XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
FOB for OEM Reference Price:Get Latest Price
$10000.00-$1000000.00 1 / EA (Min. Order)
Model: XGA16AC
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
Summary
  • Weight:6500kg
  • Overall Dimension:6.42*1.75*2m
  • Table Size:1.4*0.7m
  • Max Lifting Height:16m
  • Min Lifting Height:2m
  • Rated Loading Capacity:227kg
  • Lift Drive / Actuation:Electric Motor
  • Lift Mechanism:Articulated Lift
  • Model Number:XGA16AC
  • Brand Name:XCMG
  • Place of Origin:Xuzhou, Jiangsu, China
  • Certification:CE/ISO9001
Details
  • weight:6500.000kg
  • Condition:New
  • Moving Type:Other

XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price

XCMG 16m small boom lift XGA16AC electric articulated boom lift platform.



Electric articulated small mobile boom lift XGA16AC are developed by XCMG, compact structures and vehicle body 1.75m wide.



Intelligent and perfect control system features the humanized layout, the maintenance-free design and easy use and maintenance, providing the multiple options and comprehensive safety.



Advantages and highlights:



1.Σ-shaped boom combine and zero tail swing design make it more productive.



2.As small as 3.15m turning radius enables the machine to work in narrow space.



3.48V and 420Ah large-capacity battery makes the cruising ability longer.



4.Advanced AC motor driven technologies; steering differential control technologies; powerful and steady actions; grade ability up to 30%.



5.DC pump and proportional control technologies are energy-saving and effective, making the work steadier and safer.



6.Environment friendly, zero emission, low noise, traceless traveling, suitable for indoor construction.

XCMG 16m small boom lift XGA16AC electric articulated boom lift platform price

Item

Parameter

Parameters of running state

Overall dimensions (L × W × H)

6.42×1.75×2 m

Working platform overall dimensions

1.4×0.7×1.15 m

Max. speed

5.2 km/h

Max. gradeability

≥30%

Min. external turning radius

≤3.15 m

Ground clearance/m (center)

0.21 m

Wheelbase

2 m

Total mass

6500 kg

Main Operation Performance Parameters

Rated working height

15.5 m

Max. platform height

13.8 m

Max. working range

8 m

Max. net spanning height

7.03 m

Scope of platform swing

160°

Slewing radius of turntable

0.875 m

Max. load capacity

227 kg

Max. rearward slewing

0 m

Control system

12V DC proportional control

Tire

250-15 solid tire, optional foam tire 240/55 D17.5

Power parameters

Power source

420 Ah/48 V DC

Power unit

4 kw/48 V DC

Auxiliary power unit

2.2 kw/24 V DC

Traveling motor

3.3 kw/32 V AC

XCMG 16m small boom lift XGA16AC electric articulated boom lift platform priceXCMG 16m small boom lift XGA16AC electric articulated boom lift platform priceXCMG 16m small boom lift XGA16AC electric articulated boom lift platform priceXCMG 16m small boom lift XGA16AC electric articulated boom lift platform price
