XCMG 45 ton mini drill rig machine XR130E for sale
FOB for Piling Mach Reference Price:Get Latest Price
Chat Now 1 / EA (Min. Order)
Model: XR130E
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 45 ton mini drill rig machine XR130E for sale
XCMG 45 ton mini drill rig machine XR130E for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Details
Summary
  • Certification:CE/ISO9001
  • Dimension(L*W*H):7546×3600×17724mm
  • Weight:45000kg
  • Model Number:XR130E
  • Brand Name:XCMG
  • Place of Origin:Jiangsu,China
  • Power Type:Diesel
  • Type:Rotary Drilling Rig
Details
  • weight:45000.000kg
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Warranty:12 Months
  • Condition:New
  • Moving Type:Crawler

XCMG 45 ton mini drill rig machine XR130E for sale

XCMG 45 ton mini drill rig machine XR130E.



XR Series Mini Drill Rig stands for our company's achievement in many years' development and researches on piling machine, adopting the advanced technology, both at home and abroad. With our company's powerful machinery manufacturing capacity, it is specially designed to drill the pile hole with the big diameter and into hard—layers, fitting for layer conditions in most areas.



Performance Characteristics:

1.It adopts dedicated TDP series hydraulic retractable chassis and large—diameter slewing bearing and has high stability and convenience of transport It has long wheel base which makes it very adaptable to the terrain.



2. Transportation of the machine includes a drilling bar. Transportation width is only 2.5m and transportation height is only 3.5 m. Light transport weight makes easier to load and unload.



3. Rotary drive, main winch and auxiliary winch have high output speed, which develops the efficiency of work.



4. It adopts guangxi cummins turbocharged engine with electro—control which provides strong power and meets the requirements of EU3 emission standard, can select imported engine of cummins.



5. It adopts imported Kawasaki hydraulic system with high reliability and a lot of technology of XCMG.



6. It adopts the technology of CAN electronic control and simplify the hydraulic plumbing system which improves the reliability of the machine.



7. A variety of specifications configuration of drilling bars are available which meets the needs of different working conditions.



8. Cylinder crowded, winch crowded, drive of casing pipe, CFA, spin—off type function are optional.

XCMG 45 ton mini drill rig machine XR130E for sale

Parameter

Unit

XR130E

Engine

Model

QSB7-C227

Rated Power

kW

169

Rotary Drive

Max. output torque

kN·m

130

Rotary speed

r/min

8~35

Max. Drilling Diameter

mm

2500

Max. Drilling Depth

m

50

Main Winch

Max.Pulling force

kN

140

Max.line speed

m/min

75

Auxiliary Winch

Max.Pulling force

kN

50

Max.line speed

m/min

70

Mast Rake

Side/forwards/backwards

Undercarrige

Max. traveling speed

km/h

2.7

Max.grade ability

%

40

Min. Clearance

mm

345

Track shoe width

mm

600

Distance between tracks

mm

2500~3600

Hydraulic System

Working pressure

Mpa

35

Overall Drilling Weight

t

45

Dimension

Working condition

mm

7546×3600×17724

Transportation condition

mm

14097×2500×3500
