XCMG Official HDD Machine XZ450 Horizontal Directional Drilling with Cummins Engine

Chat Now 1 / EA (Min. Order)
Model: XZ450
Engine: Cummins
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Official HDD Machine XZ450 Horizontal Directional Drilling with Cummins Engine

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Certification:CE/ISO9001
  • Dimension(L*W*H):8960*2480*2570mm
  • Weight:18t
  • Power(W):194kw
  • Usage:Construction
  • Model Number:XZ450
  • Brand Name:XCMG
  • Place of Origin:Jiangsu, China
  • Power Type: Diesel

Specifications

  • Weight:18000.000kg
  • Condition:New
  • Moving Type:Other

XCMG Official HDD Machine XZ450 Horizontal Directional Drilling with Cummins Engine

XCMG Official HDD Machine XZ450 Horizontal Directional Drilling with Cummins Engine.



XZ Series Horizontal Directional Drills are mainly used in the trenchless piping construction and replacement of the underground pipe. The XZ Series Horizontal Directional Drills have the advantages of advanced performance, high efficiency and comfortable operation.



Many key components adopt international famous products to guarantee the quality. They are the ideal machines for the construction of the water piping, gas piping, electricity, telecommunication, heating system, crude oil industry.



Performance Characteristics:



* Pluralities of advanced control technologies are adopted, including the PLC control, electro-hydraulic proportion control, load sensitive control, etc.



* The pipe automatic disassembly and assembly device can improve the working efficiency, relieves the labor intensity and manual error operation of the operators, and reduces the construction personnel and the construction cost.



* Automatic anchor: The down and the up of the anchor is driven by hydraulics. The anchor is great in force and is easy and convenient to operate.



* The dual-speed spindle drive is operated with low speed when drilling and dragging back to ensure smooth construction, and can speed up to slide with 2 times of speed to reduce the auxiliary time and improve the working efficiency when returning and disassembling the drilling rod with empty loads.



* The engine has the turbine torque increment characteristic, which can instantly increase the power to ensure the drilling power when coming across the complex geology.

XCMG Official HDD Machine XZ450 Horizontal Directional Drilling with Cummins Engine

Model

Unit

XZ450

Engine

Cummins

Rated power

kW

194

Push-pull

Rack and pinion

Max. pullback/thrusting

kN

450/450

Spindle torque (max)

N.m

17000

Spindle speed

r/min

0-135

Taeling speed of power head

m/min

0-38

Backreaming diameter

mm

1000

Pipe length(single)

m

4.5

Pipe diameter

mm

89

Entry angle

°

10-20

Mud flow rate (max)

L/min

500

Mud pressure (max)

bar

10

Overall weight

T

18

Dimension (L*W*H)

mm

8960*2480*2570

XCMG Official HDD Machine XZ450 Horizontal Directional Drilling with Cummins Engine
