Summary
- Certification:ISO9001
- Dimension(L*W*H):18240×3000×3600mm
- Weight:55000kg
- Power(W):565kw
- Model Number:XZ6600
- Brand Name:XCMG
- Place of Origin:China
- Power Type:Diesel
- Type:Horizontal Directional Drill
Details
- Product Name:357636-XZ6600
- Display online time:2019-12-27
- weight:58000.000kg
- After-sales Service Provided:Engineers available to service machinery overseas
- Warranty:12 Months
- Condition:NEW
- Moving Type:crawler
- Max.thrust-pull force:6600kN
- Max. thrust-pull speed:28m/min
- Max. spindle speed:90r/min
- Max. inclination angle:16
- Max. torque:160000N •m
- engine model(China II ):6BTAA5.9-C180
- rated power(China II ):132/2200 kW/ r/min

XZ6600 Horizontal Directional Drill
1、Equipped with closed energy-saving circuit, load sensing control, electro-hydraulic proportional control and other advanced technology, Using the international famous brand components,reliable quality.
2、Rack and pinion sliding, ensure the stability and drive operational reliability of the Rotation box.Rotation box floating can greatly protect the drill pipe threads,improving the service life of drill pipe.
3、Volvo high horsepower engine is adopted to ensure that the drilling rig can complicated geological conditions.
4、Dual power system. Any engine start can complete all the action of the vehicle. Cummins Engine, powerful, ample power reserves to meet drill construction in different working conditions.
5、The clamp has three cylinder clamping so that drill pipe clamping reliable and shackle torque is enough. Full floating clamp, shackles torque, clamping and reliable.
6、Drill rotation and push and pull all adopt digital pressure adjustment technology. Convenient adjustment and reliable and can be preset.



Description |
Unit |
Parameter value |
|
Power house Engine |
Manufacturers |
Volvo |
|
Model |
TAD1643VE |
||
Rated Power |
kW /(r/min) |
565×2/1850 |
|
Mainframe Engine |
Manufacturers |
Cummins |
|
Model |
6BTAA5.9-C180 |
||
Rated Power |
kW /(r/min) |
132/2200 |
|
Thrust-Pull |
Max thrust-pull force |
kN |
6600 |
Max thrust-pull speed |
m/min |
28 |
|
Rotation |
Torque |
N·m |
160000 |
Max spindle speed |
r/min |
90 |
|
Loader Crance |
Max. Lifting weight |
t |
5 |
Loading capacity |
t·m |
12.5 |
|
Max inclination angle |
° |
16 |
|
Travel
driving |
Type |
Steel crawler self-propelled |
|
Traveling speed |
Km/h |
0.9 |
|
Gradeability |
% |
30 |
|
Pipe |
Diameter × Length |
mm×mm |
Φ194×9600 |
Weight |
kg |
58000 |
