XCMG Official manufacturer 3ton 6m3 small compressed garbage compactor truck XZJ5070ZYSQ5 for sale
Summary
- Certification:CE/ISO9001
- Dimension(L*W*H): 6750*1950*2400mm
- Weight:7300kg
- Model Number:XZJ5070ZYSQ5
- Brand Name:XCMG
- Place of Origin:Jiangsu,China
- Volume of tank:10001 - 15000L
Specifications
- weight:7300.000kg
- Condition:New
- Moving Type:Other
Packaging & Shipping
- Delivery Lead Time:7 days for ready goods
- Minimum Order:1 Piece
- Supply Ability:10,000 Set/ Sets per Month
- Total Quantity In Stock:Over 5000
- Delivery Port:Any Port In China
XCMG Official manufacturer 3ton 6m3 small compressed
garbage compactor truck XZJ5070ZYSQ5.
It
is the preferential vehicle for garbage collection, compression and
transportation, and single series can complete the whole process of collection
and transportation. Full-sealing design is adopted and drain tank is
elaborately set, which can realize automatic compression and unloading process
and put an end to secondary pollution. It has wide applicable scope, and it is
mainly used for garbage collection and transportation in residential quarters,
streets and campus, etc.
Performance Characteristics:
*
High Compression Ratio, Fast Loading Speed
The
design idea of bidirectional compression, XCMG high quality hydraulic system
and advanced press -loading structure is adopted; it can guarantee that
different garbage is uniformly covered by pressure, the whole container has no
dead corner, gap or blockage phenomenon, which can make the garbage volume
reduced by 66.67%. The garbage loading capacity is increased by about 20% under
the same container volume condition.
*
Reduce Noise, Eliminate Pollution
The
manufacturing idea of “make green with green" is adopted to put an end to
secondary pollution of any form. Cooperation with performed with domestic
famous universities and colleges to strictly control the noise, letting
residents enjoy a serene night. There are various sealing mechanism to lock the
garbage and prevent leakage of gas and liquid, utterly solving the problem of
secondary pollution during compression, loading and transportation.
*
Intelligent Control, Comfortable Operation
Extend
the nerve ending of product control system; wireless remote controller is
optional for operation, realizing “zero contact" between operator and
domestic garbage.
|
MODEL |
XZJ5070ZYSQ5 |
|
|
Specification |
Chassis Model |
QL1070A5HAY |
|
Vehicle Model |
3t |
|
|
Overall length |
6365mm (no feeding device) |
|
|
750mm (tipping bucket) |
||
|
6645mm (bucket shape) |
||
|
6750mm (Swing arm) |
||
|
Overall Width |
1950mm |
|
|
Overall Hight |
2400mm |
|
|
Weight |
Total Weight |
7300kg |
|
Curb Weight |
4920 kg (no feeding device) |
|
|
5090 kg (tipping bucket) |
||
|
5040 kg (bucket shape) |
||
|
5040kg (Swing arm) |
||
|
Rated Payload |
2250 kg(no feeding device) |
|
|
2080 kg (tipping bucket) |
||
|
2130 kg (bucket shape) |
||
|
2130kg (Swing arm) |
||
|
Fitted parts specifications |
The Volume of Carriage |
6m3 |
|
Fill Capacity |
1.1m3 |
|
|
Drain tank volume |
130L |
|
|
loading cycle time |
<16s |
|
|
The loading Angle of the loader |
~95° |
|
|
Hydraulic system rated pressure |
16MPa |
|
|
Main materials and their proprietary components |
Box side plate, bottom plate |
Steel plate 3.5/Q460NH |
|
Push plate front plate, box top plate |
Steel plate 2.5/Q460NH |
|
|
Push plate bottom plate |
Steel plate 6/Q460NH |
|
|
Loader rail |
Steel plate 18,10/Q390 |
|
|
Filler hopper |
Steel plate 6/WEI-TEN780RE (imported high-strength
steel) |
|
|
Floor reinforcement beam |
Steel plate 3.5/Q460 |
|
