XCMG 50 ton boom arm truck cranes QY55KA_Y for sale

  • XCMG 50 ton boom arm truck cranes QY55KA_Y for sale
  • XCMG 50 ton boom arm truck cranes QY55KA_Y for sale
  • XCMG 50 ton boom arm truck cranes QY55KA_Y for sale
  • XCMG 50 ton boom arm truck cranes QY55KA_Y for sale
  • XCMG 50 ton boom arm truck cranes QY55KA_Y for sale
  • XCMG 50 ton boom arm truck cranes QY55KA_Y for sale

Share:
XCMG 50 ton boom arm truck cranes QY55KA_Y for sale
FOB for Cranes Reference Price:Get Latest Price
$100000.00-$900000.00 1 / EA (Min. Order)
Model: QY55KA_Y
Engine: HANGFA
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 50 ton boom arm truck cranes QY55KA_Y for sale
XCMG 50 ton boom arm truck cranes QY55KA_Y for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Model Number:QY55KA_Y
  • Brand Name:XCMG
  • Place of Origin:Xuzhou,Jiangsu,China
  • Span:6.9m
  • Max. Lifting Height:58.1m
  • Max. Lifting Load:55ton
  • Rated Lifting Moment:1822kN.m
  • Rated Loading Capacity:55ton
  • Application:Construction
  • Certification:CE/ISO9001
Specifications
  • weight:38580.000kg
  • Condition:New
  • Moving Type:Wheel
  • Engine rated power:206/2200-266/2200kW/(r/min)
  • Overall dimension:13100*2750*3350mm
  • Engine rated torque:1100/1400-1460/1400N.m/(r/min)
  • Min. turning diameter:24m
  • Min.ground clearance:285mm

XCMG 50 ton boom arm truck cranes QY55KA_Y for sale

XCMG 50 ton boom arm truck cranes QY55KA_Y.



XCMG boom truck cranes QY55KA_Y newly upgraded 55-ton truck crane with compact structure and highest operating performance in the industry.



1. Leading lifting and driving performances

* Five section U-type booms. The boom length is 11.4m-43.5m with strong lifting performance, leading 5%-10% ahead of products with the same tonnages in the same industry.

* High-power engine with good dynamic performance, strong gradeability and superior trafficability. The maximum gradeability and maximum travel speed respectively are 42% and 85km/h.



2. Reliability of heat dissipation, electrical system etc. has been improved with safer operation and driving

* Waterproof connector clip. It is equipped with rubber sheath inside with excellent water impervious and level of protection reaches to IP65.



3. Mature and reliable double-pump confluence technique, maintaining the advantages of efficient operation

* The double-pump confluence technique is adopted in raising and falling of winch, extending and retracting of lazy boom and luffing, leading ahead of luffing and extending and retracting operations.



4. Air-aid shift gears and 45% of shifting force is reduced

* The boost system will work only by stepping on the clutch that effectively avoids gearbox damaging gears when shifting. Compared with the same industry, 100mm distance of shift gears and 45% of shifting force are respectively reduced.

XCMG 50 ton boom arm truck cranes QY55KA_Y for sale

Catalog
Item
   Parameter
Unit
Dimensions
Total length
13100
mm
Total width
2750
mm
Total height
3350
mm
Weight
Total weight in a traveling state
38580
kg
Front axle load
12950
kg
Rear axle load
25630
kg
Power
Engine model
Euro lll Hangfa WD615.334/Euro ll hangfa WD615.46
Rated Engine Power
206/2200 266/2200
kW/(r/min)
Engine rated torque
1100/1400 1460/1400
N.m/(r/min)
Travel
Max.travel speed
66 75
Km/h
Min.turning diameter
24
mm
Min.ground clearance
285
mm
Approach angle
16
°
Departure angle
11
°
Max.gradeability
27 46
%
Fuel consumption of 100km
42
L
Lifting performance
Max.lifting capacity
50
t
Min.rated working radius
3
m
Turning radius at swing tadble tail
3482
m

XCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for sale



uMore xcmg boom truck cranes



XCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for saleXCMG 50 ton boom arm truck cranes QY55KA_Y for sale

Send your message to this supplier
Email:
to:
XCMG E-commerce Inc.
Content:
/6000

Your inquiry content must be between 20 to 6000 characters.

Quantity:
/ Set
back to top
Response Time : Within 24 hours
XCMG was founded in 1943. XCMG products include: excavators, loaders, cranes including earth-moving machinery, road machinery, concrete machinery, mining machinery and other 12 construction machinery.
