XCMG 52m concrete pump machine HB52V with HOWO chassis for sale
FOB for Concrete Mach Reference Price:Get Latest Price
$100000.00-$200000.00 1 / EA (Min. Order)
Model: HB52V
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG 52m concrete pump machine HB52V with HOWO chassis for sale
XCMG 52m concrete pump machine HB52V with HOWO chassis for sale
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
  • 360-Degree VR Videos
  • Product PDF
Summary
  • Dimension(L*W*H):13000*2540*4000mm
  • Weight:35000kg
  • Power(W):324000W
  • Model Number:HB52V
  • Brand Name:XCMG
  • Place of Origin:Jiangsu, China
  • Power Type:Diesel
  • Certification: ISO9001
Specifications
  • weight:35000.000kg
  • Condition:New
  • Moving Type:Wheel
  • Color:Color
  • Productivity:170M3/H
  • Chassis brand: Sinotruk HOWO
  • Max. vertical conveying distance:51.2m
  • Max. horizontal conveying distance:46m

XCMG 52m concrete pump machine HB52V with HOWO chassis for sale

XCMG 52m concrete pump machine HB52V with HOWO chassis.



XCMG 52m concrete pump machine HB52V with HOWO chassis is equipped with more efficient skirt valve and S valve pump technology, more stable reversing buffer technology, more reliable full hydraulic reversing technology.

XCMG 52m concrete pump machine HB52V with HOWO chassis adopts Sinotruk HOWO chassis, which complies with China VI emission standard, featuring with powerful output, large torque, high efficiency, energy conservation and strong off-road performance.

Advantages and highlights:

1.Ultimately Safe Boom.

2. Lower Structure of High Rigidity.

3.Hydraulic System of Outstanding Performance.

4.Effectively reduce emissions with the reversing, vulnerability of longer life.

5.The pumping system adopts electric control reversing, reversing faster and the system impact smaller.

6.The actual pumping efficiency is more than 5% higher than the conventional hydraulic control reversing system.



XCMG 52m concrete pump machine HB52V with HOWO chassis for sale

Item
Unit
HB52V
Outline dimension
mm
13000*2540*4000
Overall weight
kg
35000
Brand
/
Sinotruk HOWO
Model
/
ZZ5356V524MF1
Wheelbase
mm
4800+1400
Max.power
kW
324
Emission standard
/
China VI
Theoretical
m³/h
170
Concrete pumping pressure
MPa
8
Theoretical pumping times
Times/min
23~26
Delivery cylinder diameter × stroke
mm
φ260×2000
Reach height
m
51.2
Reach depth
m
36.1
Slewing radius
m
46
Slewing angle
°
±270
Transfer
/
Rock valve/S valve

XCMG 52m concrete pump machine HB52V with HOWO chassis for sale
