Summary
- Weight:2170kg
- Table Size:2276×825mm
- Rated Loading Capacity:230kg
- Power:4×6(225)V/(Ah)
- Model Number:GTJZ0808
- Brand Name:XCMG
- Place of Origin:China
- Certification:CE/ISO9001
- Max. Lifting Height:8m
- Overall Dimension(L*W*H):2485×830×2345mm
Details
- Product Name:G5B6C0CDAA35E4
- Display online time:2019-11-07
- weight:2170.000kg
- After-sales Service Provided:Engineers available to service machinery overseas
- Warranty:12 Months
- Condition:NEW
- Moving Type:wheel
- Max. Working Height:10m
- Max. Platform Height:8m
- Platform Extension Length:900mm
- Travel Speed(High Speed):3.5km/h
- Travel Speed(low Speed):0.8km/h
- Max.Travel Platform Height:8m
- Min. Turning Radius:0m
- Max. Grade Ability:0.25
- Warning Angle of Inclination both sides/front or rear:1.5°/3°
GTJZ0808 Scissors Aerial Work
Platform:
1、Low noise and zero release
The electric drive system of zero emission,low noise, high efficiency, and high energy-conservation is applied and the traceless tires are equipped to realize environmental-friendly and convenient constructions in enclosed environments, including office buildings, hospitals, and schools.
2、Meeting individual demands
Perfect safety protection,independently-designed control system and abundant matching combinations may fully meet the customized demands of customer.
3、Compact and flexible operation
The narrow design enables the vehicle to pass through single gateway with ease and the unique “zero inner turning radius” works with folding platform to realize easier transportation and translocation and flexible application in narrow spaces. The 25% gradeability makes the driving of vehicle easier.
Description |
Unit |
Parameter value |
|
Overall length |
mm |
2485 |
|
Overall width |
mm |
830 |
|
Overall Height(Guardrail folding) |
mm |
2345(1965) |
|
Wheel Base |
mm |
1877 |
|
Maximum Working Height |
m |
10 |
|
Maximum Platform Height |
m |
8 |
|
Maximum Load Capacity |
kg |
230 |
|
Extension Platform Load |
kg |
115 |
|
Platform Size |
mm |
2276x825 |
|
Platform Extension Length |
mm |
900 |
|
Lifting Speed of Working Platform |
s |
30 |
|
Falling Speed of Working Platform |
s |
34 |
|
Total Weight |
kg |
2170 |
|
Travel Speed (High Speed) |
km/h |
3.5 |
|
Travel Speed (low Speed) |
Km/h |
0.8 |
|
Max. Travel Platform Height |
m |
8 |
|
Minimum Turning Radius |
m |
0 |
|
Minimum Ground Clearance (Pot Hole Protector Rises/Falls) |
mm |
100/20 |
|
Maximum Grade Ability |
% |
25 |
|
Tire Specification |
381x127 |
||
Battery |
V/(Ah) |
4×6(225) |
|
Charger |
A |
30 |
|
Warning Angle of Inclination |
° |
1.5 |
|
° |
3 |
Response Time : Within 24 hours
