Summary
- Size:300×80×8mm
- Model Number:NXG4250D5WC
- Brand Name:XCMG
- Place of Origin:China
- Span:70m
- Max. Lifting Height:240m
- Max. Lifting Load:12000kg
- Rated Loading Capacity:12000kg
- Application:Building Construction
- Certification:ISO9001
Details
- Product Name:357636-NXG4251D5WC
- Display online time:2019-11-14
- weight:1000.000kg
- After-sales Service Provided:Engineers available to service machinery overseas
- Warranty:12 Months
- Condition:NEW
- Moving Type:other
- Drive type:6×4
- Wheelbase(mm):3800+1350mm
- Engine Type:WP13.530E501
- Engine rated output:390/2200kw/rpm
- Engine max torque:1900/1300～1600Nm/rpm
- Engine emission standard:EURO Ⅴ
- Engine fuel tank:400L
- Transmission Type:12JSD220TA/12JSDQXL240TA
- Axle system(Front axle/Middle axle/Rear axle):7.5/7/469t
- Suspension leaf spring:3/4
- Suspension blanced suspension:Integral
- Longitudinal beam（height×width×thickness）:300×80×8mm
- Tire Type:315/80R22.5-18PR12R22.5-18PR295/80R22.5-18PR12R22.5-16PR315/80R22.5-16PR
- Brake system:Drum
- Brake system(ABS):optional
- Cab series:HANVAN G7
- Cab left/Right driving:LHD
- Cab bunk:Single
- Cab window regulator:Electric
- Cab rear window:Equipped
| Description | Parameter value | |
| Main paramet | Drive type | 6×4 |
| Gross vehicle weight(kg) | 40000 | |
| Wheelbase(mm) | 3200+1350 | |
| Engine | Type | WP13.530E501 |
| Rated output (kw/rpm) | 390/2200 | |
| Max torque(Nm/rpm) | 1900/1300～1600 | |
| Emission standard | EURO Ⅴ | |
| Fuel tank（L） | 400 | |
| Transmission | Type | 12JSD220TA/12JSDQXL240TA |
| Brand | FAST | |
| Axle system | Front axle | 7.5t/7t |
| Rear axle | 469 | |
| Suspension | Leaf spring | 3月4日 |
| Blanced suspension | Integral | |
| Frame | Longitudinal beam（height×width×thickness）/mm | 300×80×8 |
| Body | Fifth wheel | 90#/50# |
| Box/Lifting | / | |
| Tire | Type | 315/80R22.5-18PR |
| 12R22.5-18PR | ||
| 295/80R22.5-18PR | ||
| 12R22.5-16PR | ||
| 315/80R22.5-16PR | ||
| Brake system | Brake | Drum |
| ABS | optional | |
| Cab | Series | HANVAN G9LH |
| Left/Right driving | LHD | |
| Bunk | Single | |
| Window regulator | Electric | |
| Air conditioning | Equipped | |
