XCMG Official Manufacturer Trench Cutter XTC80 Diaphragm Wall Grab for sale

Chat Now 1 / EA (Min. Order)
Model: XTC80
After-sales Service: Engineers available to service machinery overseas
Min Order Quantity: 1 Unit
Delivery Time:
In Stock (Within 7 days)
Production (Within15 to 20 days)
Customization (negociated delivery time)
After-sales Service:
1. It is recommended that you keep in touch with the seller after purchasing offline...
About after-sales service:
1. It is recommended that you keep in touch with the seller after purchasing offline, who knows your equipment and working conditions and can provide you with more effective after-sales service.

2. If you purchase on Machmall.com, its customer management system will record your customer information, please rest assured to apply for after-sales service.

3. If you can't find the seller, Machmall.com will help you as long as you provide the equipment nameplate and service you want. Please inform us as much information as possible in order to get the most accurate after-sales service.

After-sales service forms:
1. Online service: samples, technical specifications, operation manuals, spare parts purchase.

2. Video service: application guidance, troubleshooting and maintenance guidance.

3. Overseas service: XCMG has a complete global after-sales service team. Please note that if there is no clear after-sales liability clause in the sales contract, we will charge the necessary service fees.
XCMG Official Manufacturer Trench Cutter XTC80 Diaphragm Wall Grab for sale

Content:

*Email:

Full Name:

Mobile phone:

  • Summary
  • Specifications

Summary

  • Overall Dimension(L*W*H): 14175×3700×3560 mm
  • Weight:138000 kg
  • Model Number: XTC80
  • Brand Name:XCMG
  • Place of Origin:China
  • Certification:CE/ISO9001

Specifications

  • Weight:138000.000kg
  • Condition:New
  • Moving Type:Crawler
  • Trench width:800—1500 mm
  • Max. wall depth:80 m
  • Trench length:2800 mm
  • Trench accuracy:3‰
  • Max. torque:2×80 kN.m
  • Rotary speed:0~25 r/min
  • Max. hoisting force:640 kN
  • Max. hoisting speed:60 m/min
  • Rope diameter:Φ26 mm
  • Slag discharge way:
  • Mud pump ability:450 m³/h
  • Type of Base Machine:Dedicated Machine
  • Work radius:4500~5200 mm
  • System pressure:32 Mpa
  • Engine Model:CUMMINS QSK23
  • Engine Rata Power:567/1800 kW/r/min
  • Track outer width:3700—5100 mm
  • Track shoe width:900 mm
  • Max. traveling speed:1 km/h
  • Max. grade ability:35%
  • Min. clearance:450 mm
  • Machine Size of Working condition:11665×6575×17500 mm
  • Machine Size of Walking state:14175×3700×3560 mm
  • Total weight:138 t

XCMG Official Manufacturer Trench Cutter XTC80 Diaphragm Wall Grab for sale

XCMG Official Manufacturer Trench Cutter XTC80 Diaphragm Wall Grab.



1.Equipped with XCMG advanced telescopic crawler undercarriage, with features of high strength, high stability and high reliability, well meet trench cutter's working conditions and easy transportation.

2. Eco-friendly, electronically-control, turbocharged, import Cummins Diesel Engine, powerful and high torque output, well matched with reliable hydraulic system, lower fuel consumption and high efficiency.

3. Adopting import double-speed gear box, main winch can accurately control trench cutter's quick up-down motion and low speed feed. Electro-hydraulically proportional follow-up control system can ensure the synchronism of slurry hose drum, hydraulic hose drum and main winch.

4. Front/rear single rope and dual winches, which substantially improves the rope's service life and safety.

5.High output torque of cutter wheels, high working efficiency, and capable of various soil layer and hard rock layer with different cutting teeth. Max. Trench80m.

6. Equipped with advanced inclinometer, longitudinal and lateral adjustment devices, providing high accuracy Omni- adjustment, recording and drawing the wall curve in real time, effectively guaranteeing the wall quality and accuracy.

7. Adopt various advanced control ways, including full power control, electric override control, load sensing control, electro-hydraulically proportional control and others, equipped with import hydraulic parts, realizing high efficiency, high accuracy and high reliability.

8. XCMG have independently developed advanced and reliable electronic control system,  integrating engine monitoring system, working condition monitoring system, adjustment system, hose synchronizing system, breakdown inspection and alarm system. Working data can be displayed and saved in real time.Ergonomically design, equipped with full-adjustable seat, air-conditioner, protection device and a large color touchable displayer, easy to operate, being comfortable, safe and reliable.

9. It is equipped with a centralized lubrication system as standard configuration; maintenance is easier.

XCMG Official Manufacturer Trench Cutter XTC80 Diaphragm Wall Grab for sale

Project Unit Parameter
Working parameter
Wall thickness (mm) 800~1500
Wall depth (m) 80
Main data
Max. hoisting force (kN) 640
Max. hoisting speed (m/min) 60
Max. torqe (kN.m) 2×80
Rotary speed (r/min) 0~25
Slag discharge way - Pump
Mud pump ability (m³/h) 450
Power parameter
Engine model - CUMMINS QSK23
Engine rated power (kW/r/min) 567/1800
Undercarrige
Max. travelling speed (km/h) 1.5
Max. grade ability (%) 35
Max. clearance (mm) 450
Track shoe width (mm) 900
Distance between tracks (mm) 3700~5100
Working condition
Total lengh (mm) 10960
Total width (mm) 5100
Total height (mm) 17500
Working radius (mm) 4500~5100
Transportation condition
Total lengh (mm) 14175
Total width (mm) 3700
Total height (mm) 3460
System parameter
Max.system pressure (MPa) 32
Max. system flow (L/min) 2×285+352
Weight parameter
Bare weight (t) 100
Frame weight (t) 30~36
