25 ton XCMG mobile truck crane QY25K-II price
FOB for Cranes Reference Price:Get Latest Price
$10000.00-$1000000.00 1 / EA (Min. Order)
Model: QY25K-II
Engine: SHANGCHAI
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
25 ton XCMG mobile truck crane QY25K-II price
25 ton XCMG mobile truck crane QY25K-II price
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
Summary
  • Model Number:QY25K-II
  • Brand Name:XCMG
  • Place of Origin:Xuzhou,Jiangsu,China
  • Span:6m
  • Max. Lifting Height:42m
  • Max. Lifting Load:25 ton
  • Rated Lifting Moment:1010kN.M
  • Application:Construction
  • Certification:CE/ISO9001
Specifications
  • weight:29400.000kg
  • Condition:New
  • Moving Type:Wheel
  • Engine rated power:206/2200-312/2200kw/(r/min)
  • Engine rated torque:1112/1400-1160/1400N.m/(r/min)
  • Max. travel speed:75km/h
  • Min. turning diameter:21.5m

25 ton XCMG mobile truck crane QY25K-II price

25 ton XCMG mobile truck crane QY25K-II.



XCMG truck crane QY25K-II is the most popular model of China 25t truck crane, is technology crystallization which our company applies for many years manufacturing experience,bases on the mature technology.



XCMG truck crane QY25K-II is widely used for lifting operation and installation work in urban renewal, transportation, ports, bridges, oilfield, industrial and mining enterprises, etc.



Advantages and highlights:



1. Bi-hexagonal cross-section boom has small depth-width ratio, strong bearing capacity, small deformation, strong anti-bending and powerful lifting capacity.



2.Plug-in boom head effectively increases the boom connect length and reduces boom deformation.



3. It has superior travel and grade ability. The max. grade ability is 40%, max. travel speed is 80km/h.



4. Open fixed displacement pump and variable displacement motor system is adopted.



5.High pressure variable displacement motor contributes to light load with high speed and heavy load with low speed.

25 ton XCMG mobile truck crane QY25K-II price

Catalog
Item
QY25K-II
Unit
Dimensions
Total length
12650
mm
Total width
2500
mm
Total height
3380
mm
Weight
Operating Weight
29400
Kg
Front axle load
6200
Kg
Rear axle load
23200
Kg
Power
Engine model
SC8DK280Q3/WD615.329

Engine power ratings
206/2200   312/2200
Kw(r/min)
Engine torque ratings
1112/1400  1160/1400
N.m(r/min)
Travel
Max.travel diameter
75
Km/h
Min.turning diameter
21.5
m
Min.ground clearance
275
mm
Approach angle
16
.
Departure angle
13
.
Max.gradeability
30
%
Fuel consumption of 100km
37
L
Driving Parameters
Max.total lifting capacity
25
t
Min. working radius
3000
mm
Turning  radius at swing table tail
3.065
m
Max.lifting torque
1010
Kn.m
Basic boom lifting length
10.7
m
Longest boom lifting length with secondary arm
42.15
m
Longest boom lifting length
34.19
m
Outrigger longitudinal distance span
5.14
m
Outrigger lareral distance span
6
m
Working speed
Elevation duration for secondary boom
75
s
Elevation duration for fully extended boom
100
s
Max.rotation speed
≥2.5
r/min
Max.speed for main winch
≥120
m/min
Max.speed  for auxiliary  winch
≥120
m/min
