XCMG HB48K 48 meters pump for concrete machine price for Bengal
FOB for Concrete Mach Reference Price:Get Latest Price
$100000.00-$200000.00 1 / EA (Min. Order)
Model: HB48K
Warranty: One Year
After-sales Service: Engineers available to service machinery overseas
Shipping:
Support Sea freight · Land freight · Air freight
Payment Method:
XCMG HB48K 48 meters pump for concrete machine price for Bengal
XCMG HB48K 48 meters pump for concrete machine price for Bengal
Quantity:
- + /EA
Please leave your contact information and the products you want to visit. Our engineers will take you to visit 12 subsidiaries of XCMG Group and their related products online.

Name:

Country:

Please fill in the country correctly, we will present in different languages.

*Email:

Mobile phone:

Other:

  • Summary
  • Specifications
  • 360-Degree VR Videos
  • Product PDF
Summary
  • Dimension(L*W*H):12510*2500*3990mm
  • Weight: 33000kg
  • Power(W):297000
  • Model Number:HB48K
  • Brand Name:XCMG
  • Place of Origin: Jiangsu, China
  • Power Type: Diesel
  • Certification: ISO9001
Specifications
  • weight:33000.000kg
  • Condition:New
  • Moving Type:Wheel
  • Color:Color

XCMG HB48K 48 meters pump for concrete machine price for Bengal

XCMG HB48K 48 meters pump for concrete machine price for Bengal.



XCMG HB48K 48 meters pump for concrete machine has a new generation of micro-control technology used to make boom operation steadier and more accurate.

On the basis of the design concept of high rigidity structure, simulative calculation and testing of full-work-condition loading make chassis structure deformation smaller and overall work stability higher.

Advantages:

1.Intelligent control system.

2.Efficient pumping system of rock valve.

3.Hydraulic system of outstanding performance.

4.Easy-wear parts with super-long service life.

XCMG HB48K 48 meters pump for concrete machine price for Bengal

Description
Unit
Parameter value
Outline dimension
mm
12510×2500×3990
Overall weight
kg
33000
Model

ZZ5347V484MC1
Manufacturer

Sinotruk Group Jinan Truck Co.
Max. speed
km/h
90
Max. grade-ability
%
40
Wheelbase
mm
4800+1400
Tire

315/80R22.5
Model

MC11.40-30
Max. power
kW
297
Max. torque
N·m/(r/min)
1900/1000~1400
Displacement
L
10.518
Emission standard

Eruo III
Theoretical output
m³/h
170
Concrete pumping pressure
MPa
8
Theoretical pumping times
Time/min
23~26
Delivery cylinder diameter ×stroke
mm
φ260×2000
Max. diameter of pumping concrete
mm
≤40
Filling height
mm
1580
Concrete slump range
cm
8~23
Reach height
m
47.5
Reach depth
m
34
Slewingradius
m
43.5
Slewing angle
°
±270
Unfolding angle of the 1st section
°
90
Unfolding angle of the 2nd section
°
180
Unfolding angle of the 3rd section
°
180
Unfolding angle of the 4th section
°
240
Unfolding angle of the 5th section
°
210
Unfolding angle of the 6th section
°
120
Longitudinal span of stabilizer
mm
8955
Transverse span of front stabilizer
mm
7884
Transverse span of rear stabilizer
mm
9940
Transfer tube

Rock valve
Lubrication method

Automatic lubrication
